- Page 1 Manual Spade 1.5 Hp 1/2" Handle Drill Power Chuck Applies for Code Model 16714 TALE-1/2N TALE-1/2N Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Assembly auxiliary handles Keep this manual for future references. Start Up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Notes Authorized Service Centers Warranty Policy TALE-1/2N ENGLISH... -
Page 3: Technical Data
Technical Data TALE-1/2N Code 16714 Description Spade Handle Drill Chuck 1/2" Voltage 127 V Frequency 60 Hz Current 8.9 A Power 1.5 Hp Drilling Capacity Wood: 1-1/2” | Metal: 1/2” Speed 0 RPM - 620 RPM Duty Cycle 50 minutes work per 20 minutes idle. Maximum 6 hours per day. -
Page 4: General Power Tool Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Warnings For Drills
Safety warnings for drills Choose the right bit While operating the drill CAUTION • Choose the right bit for the work piece. • Use the auxiliary handles, if supplied with the tool. It reduces the risk of severe injury and makes the job easier. Loss of control may result in personal injury. -
Page 6: Parts
Parts Auxiliary Handle Assembling Orifice “D” Auxiliary Rear Handle Angle Chuck “D” Auxiliary Handle Continuous Speed Rotation operation button control selector lever Switch Handle Chuck wrench Auxiliary handle Power cord Power protector feed cord Chuck key holder Assembly auxiliary handles To increase torque, you may use both auxiliary handles with the continuous button activated. -
Page 7: Start Up
Start Up Chuck Bit Fitting • Introduce the bit into the chuck until it stops. Fasten with the chuck wrench and tighten alternately the chuck into each of the orifices. WARNING Clean burrs and any other foreign objects from the drill bit and drill bit, otherwise the drill bit may not be tight and cause serious personal injury. -
Page 8: Maintenance
Maintenance Chuck Change • Remove the auxiliary handle and open wide the chuck jaws. • Using a screwdriver remove the left-threaded safety screw with a clockwise movement. Phillips • Fit the long side of an “L” (not included) Allen key in a Screwdriver vise and insert the short side of the “L”... -
Page 9: Notes
Notes ENGLISH... - Page 10 Notes ENGLISH...
-
Page 11: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 12: Warranty Policy
® require any proof of purchase to make the warranty effective. Phone number 800-018-7873. Made in China. Imported by Truper, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
