Summary of Contents for Truper TAL-1/4N
- Page 1 Manual Drill 380 W 1/4” Power Chuck Applies for: Code Model 103067 TAL-1/4N TAL-1/4N TAL-1/4N Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Manual before Parts using the tool. Preparation Keep this manual for future references. Start up The illustrations in this manual are for reference Maintenance only. They might be different from the real tool. Notes Authorized service centers Warranty policy TAL-1/4N ENGLISH... -
Page 3: Technical Data
Technical data TAL-1/4N Code 103067 Description Drill Chuck 1/4” (6.5 mm) Voltage 127 V~ Frequency 60 Hz Current 3.2 A Power 380 W Speed 0 RPM - 3 300 RPM Drilling Capacity Steel: 15/64” | Wood: 19/32” Duty cycle 50 minutes work per 20 minutes idle. -
Page 4: General Power Tools Safety Warnings
General power tool safety warnings WARNING! Read carefully all safety warnings and instructions listed below. Failure to comply with any of these warnings may result in electric shock, fire and / or severe damage. Save all warnings and instructions for future references. -
Page 5: Safety Standards For Drills
Safety standards for drills Choose the right bit While operating the drill CAUTION • Choose the right bit for the work piece. • Use the auxiliary handles, if supplied with the tool. It reduces the risk of severe injury and makes the job easier. Loss of control may result in personal injury. -
Page 6: Parts
Parts Belt clip 1/4” Heavy duty chuck Handle Lock-on button Variable speed Forward / reverse control trigger control lever Switch Power cord guard Chuck wrench holder Chuck Power cord wrench ENGLISH... -
Page 7: Preparation
Preparation Bit fitting Chuck • Put the bit into the chuck until it stops. Fasten with the chuck wrench and tighten alternatively the chuck into each of the orifices. WARNING Clean burrs and any other foreign objects from the drill bit and drill bit, otherwise the drill bit may not be tight and cause serious personal injury. -
Page 8: Maintenance
Maintenance Chuck Change Chuck with wrench • Insert the bit as deep as possible in the chuck. Do not use bits with a damaged shank WARNING Use the appropriate bits WARNING Only use sharp bits. • For drilling in concrete or stone a steady pressure on the drill is required •... -
Page 9: Notes
Notes ENGLISH... - Page 10 Notes ENGLISH...
-
Page 11: Authorized Service Centers
In the event of any problem contacting a TRUPER Authorized Service Center, please see our webpage WWW.TRUPER.COM to get an updated list, or call our toll-free numbers 800 690-6990 or 800 018-7873 to get information about the nearest Service Center. -
Page 12: Warranty Policy
Phone number 800-018-7873. Made in China. Imported by TRUPER, S.A. de C.V. Parque Industrial 1, Parque Industrial Jilotepec, Jilotepec, Edo. de Méx. C.P. 54257, Phone number 761 782 9100.
