- Page 1 Manual Reversible 3/8” Air Drill Chuck Applies for: Code Model 19368 TPN-788RX TPN-788RX Use oil continuously and WARNING dosed to lubricate the tool. Read this manual thoroughly CAUTION before using the tool.
-
Page 2: Table Of Contents
Parts Keep this manual for future references. Assembly The illustrations in this manual are for reference Star up only. They might be different from the real tool. Maintenance Authorized service centers Warranty policy TPN-788RX ENGLISH... -
Page 3: Technical Data
Technical Data TPN-788RX Code 19368 Description Reversible air drill Chuck 3/8” Air Output Bottom Noise Level 83 dB Vibration > 2.5 m/s Free Speed 1 800 RPM Weight Without Accessories 2.42 lb Total Length 6-7/8” Air Pressure 90 PSI Air Consumption... -
Page 4: General Safety Warnings For Pneumatic Tools
General Safety Warnings for Pneumatic Tools Keep your work area clean, tidy and well lit. Wear adequate protective safety accessories. CAUTION CAUTION Cluttered and dark areas may cause accidents. Wear eye protection, dust mask, non-skid safety shoes, helmet and ear plugs. In normal conditions, the risk of Never use the tool in explosive areas or in the presence injury is reduced. -
Page 5: Risk Control When Using Pneumatic Tools
Risk Control When Using Pneumatic Tools Risk of injury in head and eyes To prevent head and eyes injuries WARNING • Compressed air out of pneumatic • Always, when operating pneumatic equipment wear equipment may be dangerous. Objects like brackets, burrs, protection glasses in compliance with the AMSI Z887.1 splinters, dust and other residues may be impelled towards Standard. - Page 6 Risk Control When Using Pneumatic Tools Risk of injuries To prevent injuries WARNING • Damaged hoses may burst and cause • Do not abuse the hose or the connectors. serious injuries or deafness. • Keep the hose away from sharp or abrasive edges. •...
-
Page 7: Parts
Parts Chuck Handle Trigger Rotary Selector Chuck Excess Oil Input Exhaust Assembly Chuck Bit Installation • Set the bit into the chuck until it stops. Secure it with the chuck key tightening the chuck in each one of the orifices alternately. Chuck Air intake connection •... -
Page 8: Star Up
Star Up Turning On • Turn ON the compressor and let it fill up. • Regulate the air compressor output pressure from 621 to Trigger 793 kPa (90 – 115 PSI). WARNING The tool operates at this pressure range. Operating in the higher-pressure range will result in a shorter tool life. -
Page 9: Authorized Service Centers
Authorized Service Centers In the event of any problem contacting a Truper Authorized Service Center, please see our webpage www.truper.com to get an updated list, or call our toll-free numbers 800 690-6990 or 800 0187-8737 to get information about the nearest Service Center. -
Page 10: Warranty Policy
. Transportation costs resulting from compliance of this warranty will be covered by For questions or comments, call 800-690-6990. Made in China. Imported by Truper S.A. de C.V. Parque Industrial 1, Jilotepec, Edo. de Méx. C.P. 54240 Stamp of the business.
