- Page 1 S1900-8TP Switch Hardware Installation and Maintenance Guide V1.0.2307A Innovation · Expertise · Agility...
-
Page 2: Safety Statement
Preface Audience This document is intended for network engineers responsible for S1900-8TP switch installation and maintenance. You should have experience in network device installation and maintenance. Feature Statement Please visit the FS.COM Technical Documents page to download the datasheet and obtain information on the specifications supported by the product. -
Page 3: Table Of Contents
Contents Hardware Installation and Parts Replacement 1.1 Installation Procedure 1.2 Installation Preparation 1.3 Installing a Switch 1.4 Device Connection 1.5 Post-Installation Checks Innovation · Expertise · Agility... - Page 4 LED indicators for quick assessment of the switch's operational status, aiding in the diagnosis of network issues. All 8 RJ45 ports of the S1900-8TP have PoE power supply capabilities, supporting the IEEE802.3at standard and backward compatible with the IEEE802.3af standard. It can...
-
Page 5: Installation Procedure
• Mounting the Switch on a Wall: Anti-static bracelet (or gloves), ladder, screwdriver, marker, impact drill, rubber mallet 1.2.1 Checking the Installation Site The S1900-8TP switch must be used indoors. To ensure normal operations and long service life of the device, the installation site must meet the following requirements. Item... -
Page 6: Installation Precautions
Dust-free paper and fiber end-face microscope Meters Multimeter, bit error rate tester (BERT), and optical power meter The S1900-8TP switch is delivered without a tool kit. You need to prepare a tool kit by yourself. • 1.2.3 Installation Precautions Please follow the instructions below to install the switch to avoid equipment damage and security threats caused by incorrect operation: •... -
Page 7: Installing A Switch
Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide 1.3 Installing a Switch 1.3.1 Mounting the Switch on a Workbench Install the switch on a smooth desktop. Install the supplied rubber feet on the four corners of the bottom surface of the switch and place them in the designated locations on the desktop, reserving enough ventilation space for the switch to dissipate heat. -
Page 8: Device Connection
Power cord requirement: 10A power cord • PD Power Wiring: The PoE power design of the S1900-8TP switch supports the power supply standards of IEEE802.3af • and 802.3at, using Alternative A mode for power supply. This means power is supplied through the standard Ethernet port with 12+ and 36- connections. - Page 9 Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide The switch is powered by an internal high-efficiency power supply with AC input ranging from 100 to 240V and a frequency of 50/60Hz. Please follow the steps below to connect: AC Outlet: •...
-
Page 10: Post-Installation Checks
Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide Indicator Light Explanation: Indicator Light Panel Label Status Meaning Light Off Switch is not powered on Power Indicator Light Light On Switch is powered on Light Off Port not linked 10/100/1000Base-T Link/ACT Green Solid... - Page 11 FS has invested resources in product R&D, quality control, intelligent manufacturing, industry-leading experts, professional technical support, and networking solutions. All is to provide customers with higher-performance, lower-power consumption, and the most cost-effective products, promoting clients' network upgrades. For more information and technical support, welcome to contact us at www.fs.com/contact_us...
