Preface Audience This document is intended for network engineers responsible for S1900-5T switch installation and maintenance. You should have experience in network device installation and maintenance. Feature Statement Please visit the FS.COM Technical Documents page to download the datasheet and obtain information on the specifications supported by the product.
Contents Hardware Installation and Parts Replacement 1.1 Installation Procedure 1.2 Installation Preparation 1.3 Installing a Switch 1.4 Device Connection 1.5 Post-Installation Checks Innovation · Expertise · Agility...
Page 4
Hardware Installation and Parts Replacement FS S1900-5T is a full Gigabit Ethernet switch product that provides five 10/100/1000Mbps adaptive RJ45 ports and supports wire-speed forwarding on all ports. Based on Gigabit Ethernet network technology, it effectively avoids network transmission bottlenecks and has good network adaptability.
• Mounting the Switch on a Wall: Anti-static bracelet (or gloves), ladder, screwdriver, marker, impact drill, rubber mallet 1.2.1 Checking the Installation Site The S1900-5T switch must be used indoors. To ensure normal operations and long service life of the device, the installation site must meet the following requirements. Item...
Dust-free paper and fiber end-face microscope Meters Multimeter, bit error rate tester (BERT), and optical power meter The S1900-5T switch is delivered without a tool kit. You need to prepare a tool kit by yourself. • 1.2.3 Installation Precautions Please follow the instructions below to install the switch to avoid equipment damage and security threats caused by incorrect operation: •...
Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide 1.3 Installing a Switch 1.3.1 Mounting the Switch on a Workbench Install the switch on a smooth desktop. Install the supplied rubber feet on the four corners of the bottom surface of the switch and place them in the designated locations on the desktop, reserving enough ventilation space for the switch to dissipate heat.
Page 8
Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide Step 2: Insert the screws into the expansion tubes. Figure 3: Inserting Screws Step 3: Hang the switch on the two screws. Figure 4: Hanging the Switch Innovation · Expertise · Agility...
Step 4: Installation is complete. Figure 5: Complete Installation 1.4 Device Connection 1.4.1 Connecting Power Cables The S1900-5T switch power supply uses direct current (DC) input: Rated current: 1A • Rated voltage: 5V • The switch is powered by an external DC adapter with a power of 5V/1A. Please follow the steps below to...
Page 10
Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide 1.4.2 Connecting Switch to Computer (NIC) or Other Devices Figure 6: Devices Connected to Switch Indicator Light Explanation: Indicator Light Panel Label Status Meaning Light Off Switch is not powered on Power Indicator Light Green Solid Switch is powered on...
Hardware Installation and Parts Replacement Switch Hardware Installation and Maintenance Guide 1.5 Post-Installation Checks • If the switch is installed in a rack, please check if the installation angle iron of the rack and the switch is secure. If it is installed on a workbench, check if there is sufficient ventilation space around the switch and if the workbench is stable.
Page 12
FS has invested resources in product R&D, quality control, intelligent manufacturing, industry-leading experts, professional technical support, and networking solutions. All is to provide customers with higher-performance, lower-power consumption, and the most cost-effective products, promoting clients' network upgrades. For more information and technical support, welcome to contact us at www.fs.com/contact_us...
