Getting started with the AEK-MCU-C4MINI1 MCU and motor control evaluation
board based on the Chorus SPC58EC80E5 automotive microcontroller
Introduction
Several key trends are promoting a change in the way vehicles are designed and built. The number of electronic control units
(ECUs) in a vehicle is growing, creating complexity in the wiring needed for power and data distribution. At the same time,
electrical power requirements are evolving to enable greater electrification, towards hybrid and full battery electric vehicles.
The automotive sector natural evolution is represented by new domain and zone architectures. The first one, based on domain
controllers, is related to coordination and consolidation of functional domains, such as body domain, powertrain domain, and
ADAS domain, while the second one, based on zone controllers, aims at reducing the complexity of the wiring harness and
thereby vehicle weight and cost.
Zone controllers are hubs for power distribution and data connection requirements for sensors, peripherals, and actuators,
within a physical section of the vehicle. A mix of both architectural approaches is also envisaged.
Our new
AEK-MCU-C4MINI1
domain/zone controller. It can also be used as an automotive gateway and general purpose automotive MCU board.
Indeed, our board provides more than a standard MCU board features. Leveraging on a user-friendly interface, it allows ECU
fast prototyping with basic motor control drives included.
The
AEK-MCU-C4MINI1
is designed to address Automotive and Transportation applications as well as other applications
requiring automotive safety and security levels. A cryptography MCU core, employed as hardware secure module (HSM), is
paired with dual 180 MHz general-purpose 32-bit cores, all hosted by the on board SPC58EC80E5 MCU, featuring a total of 4
MB of flash memory.
The board layout has been conceived to speed up the user development offering an easy prototyping evaluation tool.
Despite several connection possibilities due to the MCU numerous peripherals, the user-friendly interface facilitates the
interconnection of pre-configured and pin pre-mapped peripherals.
The general-purpose and serial connectors have been standardized and grouped by peripheral function types.
The MCU peripherals are extended with the VNH7040AY embedded H-bridge motor driver for DC motor control, featuring
advanced diagnostic features (short-to-ground, short-to-battery, and open load conditions). The board has a dedicated supply
capacity for an external 5 V or 3.3 V load with maximum current capability of 2.75 A.
The
AEK-MCU-C4MINI1
allows plugging an
purposes, such as monitoring the motor current, printing serial data, or for hardware debugging, without the need of connecting
any PC terminal console. For this LCD board, two connectors are provided on the board, one on the top and one on the bottom.
The two connectors shall not be connected and used at the same time.
The top connection facilitates the debugging phase (for example, when testing signal connections and data exchange), while
the bottom one reduces the total occupied space by the two boards, making it the preferred choice for deployment purposes.
The MCU ADC reference voltage is provided by a stable linear voltage regulator (LDO) embedded in the L5963 IC.
The board hosts an OpenOCD debugger/programmer, several MCU peripheral connectors as well as various general-purpose
buttons and LEDs.
For system reset during the development phase, a reset button was added to the board layout. In addition, a reverse battery
protection circuit has been integrated for higher safety.
Warning:
The
AEK-MCU-C4MINI1
laboratory use only.
UM3350 - Rev 1 - June 2024
For further information contact your local STMicroelectronics sales office.
MCU and DC motor control evaluation board fits well in this framework, as it can be exploited as a
AEK-LCD-DT028V1
evaluation board has not to be used in a vehicle as it is designed for R&D
touch display board for multiple application and debug
UM3350
User manual
www.st.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ST AEK-MCU-C4MINI1
Summary of Contents for ST AEK-MCU-C4MINI1
- Page 1 UM3350 User manual Getting started with the AEK-MCU-C4MINI1 MCU and motor control evaluation board based on the Chorus SPC58EC80E5 automotive microcontroller Introduction Several key trends are promoting a change in the way vehicles are designed and built. The number of electronic control units (ECUs) in a vehicle is growing, creating complexity in the wiring needed for power and data distribution.
-
Page 2: Figure 1. Aek-Mcu-C4Mini1 Evaluation Board Top View
UM3350 Figure 1. AEK-MCU-C4MINI1 evaluation board top view Figure 2. AEK-MCU-C4MINI1 evaluation board bottom view Notice: For dedicated assistance, please submit a request through our online support portal at www.st.com/support. UM3350 - Rev 1 page 2/79... -
Page 3: Hardware Overview
8. External supply voltage connectors 9. External supply ADC connectors 10. 12 V DC power supply connectors 11. Switches ON/OFF 12 V DC power supply Figure 3. AEK-MCU-C4MINI1 evaluation board, top view: main components UM3350 - Rev 1 page 3/79... -
Page 4: Figure 4. Aek-Mcu-C4Mini1 Evaluation Board, Bottom View: Main Components
3. FTDI chip 4. OpenOCD debugger/programmer connector 5. JTAG connector 6. Plug connector for the AEK-LCD-DT028V1 board 7. VND7E040AJ actuators 8. VNH7040AY H-bridge driver 9. SPC58EC80E5 microcontroller Figure 4. AEK-MCU-C4MINI1 evaluation board, bottom view: main components UM3350 - Rev 1 page 4/79... -
Page 5: Spc58Ec80E5
LDO. This IC is fit for the automotive segment, where load dump protection and wide input voltage range are mandatory. The AEK-MCU-C4MINI1 hosts two L5963 devices to offer an internal and an external supply voltage. The L5963 features available in the AEK-MCU-C4MINI1 are: •... -
Page 6: L5963 Control
UM3350 Hardware overview Some of the L5963 features are not implemented in the AEK-MCU-C4MINI1: • On the board, we do not consider the Power-good reset and the Power-good function and the low voltage warning monitor that have the function of monitoring, respectively, the linear regulator, the DC/DC1 output and DC/DC2. -
Page 7: Internal Supply
5 V and 3.3 V with a capability of 2.75 A, ensuring stability and reaching the lowest voltage ripple. As shown in the figure above, the AEK-MCU-C4MINI1 board supply can be divided into two parts (external and internal) to ensure high-level safety. Indeed, the external supply does not manage the internal one. They are completely separated. -
Page 8: Figure 8. External Power Supply
UM3350 Hardware overview The board features other two external supply voltages, which provide 3.3 V (through J6) and 5 V (through J5) to the external ADC supply voltage. Figure 8. External power supply UM3350 - Rev 1 page 8/79... -
Page 9: Vnh7040Ay
The AEK-MCU-C4MINI1 microcontroller board allows using a resistive or inductive load up to 3 A. To exploit the full functionality of an H-bridge or drive a high current load, we recommend using a dedicated... -
Page 10: Working Principle
UM3350 Hardware overview Figure 9. AEK-MCU-C4MINI1 VNH7040AY block diagram The figure above shows the block diagram allowing the motor connection. 1.4.2 Working principle The motor can be independently controlled through specific combinations of INA, INB and PWM on the H-bridge. -
Page 11: Figure 11. Clockwise Direction
UM3350 Hardware overview 1.4.2.1 Clockwise direction Figure 11. Clockwise direction Set INA=H, INB=L and PWM=Duty cycle to a given % on H-B left to activate the M motor clockwise. Use PWM pin to vary the rotational speed. 1.4.2.2 Counterclockwise direction Figure 12. -
Page 12: Multisense Considerations
UM3350 Hardware overview 1.4.2.3 Brake Figure 13. Braking the motor Set INA=L, INB=L and PWM=Duty cycle (100%) on H-B left to brake the M motor (as indicated by the red arrow in the figure above). In this case, the motor is braked to GND. Essentially, since there is no difference in polarity at the ends of the motor, it will be stopped. -
Page 13: Figure 14. Current Monitoring
UM3350 Hardware overview Figure 14. Current monitoring 1.4.3.2 Embedded protection VNH7040AY driver integrates advanced protection functions to protect both the power stage and the load. The device must be protected against overvoltage, overcurrent and overtemperature events outside the safe operating area. -
Page 14: Vnd7E040Aj
The device is designed to drive 12 V automotive grounded loads as resistive, inductive, and capacitive or also automotive lamps. The chip can provide protection and diagnostics. The VND7E040AJ features available in the AEK-MCU-C4MINI1 are: • Output current: 3 A •... -
Page 15: Vnd7E040Aj In The Aek-Mcu-C4Mini
Output protected against short to ground and short to VCC – Electrostatic discharge protection – Load current limitation • In the AEK-MCU-C4MINI1 the FaultRST pin was kept low to set the faults in auto-restart mode. Note: For further information about the compensation network, refer to the VND7E040AJ datasheet. 1.5.1... -
Page 16: Multisense Considerations
UM3350 Hardware overview Figure 18. High-side configuration on the VND7E040AJ If the input is high, the switch will close, and the current will flow; otherwise, the opposite behavior will occur. The onboard LEDs (D33, D34, D36 and D37) indicate if the outputs are on or off. 1.5.3 MultiSense considerations The VND7140AJ embeds Multisense diagnostic functions that are used to sense the current, i.e. -
Page 17: Figure 20. Open Load/Sh To
UM3350 Hardware overview 1.5.3.2.1 Open load detection in off-state / Short to V The open load (OL) detection in off-state operates in the condition where the device is OFF (INPUT0 set low and SEL0 is high). The OL detection and the short to VCC is performed by reading the CS pin output. So, both conditions need a pull up resistor (R ) (in this case, R168), applied over switched circuitry, as shown in the red rectangle below. -
Page 18: Other Ics
20 kBauds and is compliant with LIN 2.0, LIN 2.1, LIN 2.2, LIN 2.2A and SAE J2602. In the AEK-MCU-C4MINI1 board, the LIN transceiver was used to build a master configuration in the LIN protocol. -
Page 19: Connector Overview
UM3350 Hardware overview Connector overview Connectors are grouped by type, to facilitate the connection and simplify the identification of the pins that can be used according to the user’s application. The microcontroller peripherals are already mapped on the connector by direct connection of the pin. -
Page 20: Figure 22. Connector Overview (Top View)
UM3350 Hardware overview Figure 22. Connector overview (top view) Figure 23. Connector overview (bottom view) UM3350 - Rev 1 page 20/79... -
Page 21: Can Connectors
Figure 25. Example of CAN signals The AEK-MCU-C4MINI1 hosts three CAN connectors with respective CAN-FD transceivers able to support high- speed applications. Each connector has two pins that indicate high and low signals, as shown in the figure above. 1.7.2... -
Page 22: 3.3 V External Power Connector
The AEK-MCU-C4MINI1 hosts six SPI connectors. Each connector has 8 pins. 5 pins are dedicated to the SPI protocol. 3.3 V external and 5 V external power supplies and a GND pin are also present. -
Page 23: Generic I/O Connectors
UM3350 Hardware overview The AEK-MCU-C4MINI1 hosts two power connectors with 3.3 V and 5 V external power supplies. Moreover, for each connector, there are four GND pins. 1.7.4 Generic I/O connectors The AEK-MCU-C4MINI1 hosts five generic I/O connectors. These connectors are a combination of different functionalities of the microcontroller: general purpose I/O, ADC, TIMER, EMIOS and INTERRUPT, as shown as example below. -
Page 24: Serial Connectors
UM3350 Hardware overview Figure 31. Display connector bottom view 1.7.6 Serial connectors 1.7.6.1 UART connector Figure 32. UART connector The UART connector implements the UART protocol used for asynchronous serial communication, which allows configuring data format and transmission speeds. It sends data bits one by one, from the least significant to the most significant, framed by start and stop bits so that precise timing is handled by the communication channel. -
Page 25: Figure 33. Lin Connector
UM3350 Hardware overview The AEK-MCU-C4MINI1 hosts a UART connector, which has two pins. TX pin is used for data transmission and RX pin is used for data reception. Referring to Figure 4, you can notice that there is another UART connector (OpenOCD debugger/programmer connector, indicated by number 4), which allows you to flash the board or use the serial line integrated in the FTDI chip (indicated by the number 3 in the figure). -
Page 26: Figure 34. I2C Connector
It is widely used to connect lower-speed peripheral ICs to microcontrollers in short- distance (so, for intra-board communication). The AEK-MCU-C4MINI1 hosts an I2C connector and has two pins that indicate the SDA (serial data line) and SCL signal (serial clock line), as shown in Figure 34. -
Page 27: Autodevkit Ecosystem
The following procedure provides step-by-step guide to create a new project in AutoDevKit Studio using the AEK- MCU-C4MINI1. Step 1. Install AutoDevKit Studio (downloadable from www.st.com/autodevkitsw). Step 2. Create a new SPC5 application: – Select [File] [New] [SPC5 C/C++ Application] Figure 35. New Project menu –... -
Page 28: Figure 37. New Application Details Page
UM3350 AutoDevKit ecosystem Step 3. Fill in the application details and then click on the [Next] Button. Figure 37. New application details page Step 4. Select the SPC58ECxx component and select the [Finish] button. Figure 38. New application MCU platform UM3350 - Rev 1 page 28/79... -
Page 29: How To Add Components To An Autodevkit Studio Project For Aek-Mcu-C4Mini
UM3350 AutoDevKit ecosystem Step 5. Click on the [Generate application code] button. A base C project is created in the workspace. Figure 39. New SPC5 application files in outline view There are two fundamental files visible in the application tree view: –... -
Page 30: Figure 41. Open Available Components List
UM3350 AutoDevKit ecosystem Step 2. To view the available components for the chosen platform: – right click on the mouse and select add – select the + icon in the project explorer Figure 41. Open available components list UM3350 - Rev 1 page 30/79... -
Page 31: Figure 42. Select Available Components For Platform
UM3350 AutoDevKit ecosystem Step 3. Select the components listed below and click the [OK] button. – SPC58ECxx Init Package Component – Low Level Driver – AutoDevKit AEK-C4MINI1 Board Component Figure 42. Select available components for platform The added components appear in the Application Name Folder: –... -
Page 32: Figure 43. New Components Visible In Project Tree
UM3350 AutoDevKit ecosystem Figure 43. New components visible in project tree In addition, the PinMap Editor icon also becomes selectable in the Editors tab: Figure 44. PinMap editor icon in Editors tab Step 4. Open Pin Map Editor to check all Pins have been allocated. Step 5. -
Page 33: How To Select A Connector On The Aek-Mcu-C4Mini
UM3350 AutoDevKit ecosystem How to select a connector on the AEK-MCU-C4MINI As mentioned above, the AEK-MCU-C4MINI evaluation board offers among its key features not only physical connection of all connector pins but also pre-assignment of these pins in the PinMap Editor, making it easy and quick to use. - Page 34 UM3350 AutoDevKit ecosystem Table 1. Pins and related configurations AEK-MCU-C4MINI AEK-MCU-C4MINI Interface MCU pad MCU pin number Functionality Connector pin label General purpose GPIO5 PB11 General purpose GPIO4 PB10 General purpose GPIO3 Analog-to-Digital ADC9 Converter (ADC) Analog-to-Digital ADC8 Converter (ADC) Analog-to-Digital ADC7 Converter (ADC)
- Page 35 UM3350 AutoDevKit ecosystem AEK-MCU-C4MINI AEK-MCU-C4MINI Interface MCU pad MCU pin number Functionality Connector pin label 5V-E 5V_Ext 5V external supply 5V-E 5V_Ext 5V external supply 5V-E 5V_Ext 5V external supply General purpose GPIO11 PC14 General purpose GPIO10 PC15 Emios used as a TIME8 PE11 timer...
- Page 36 UM3350 AutoDevKit ecosystem AEK-MCU-C4MINI AEK-MCU-C4MINI Interface MCU pad MCU pin number Functionality Connector pin label 3.3V external 3V3-E 3V3_Ext supply 3.3V external 3V3-E 3V3_Ext supply 3.3V external 3V3-E 3V3_Ext supply 3.3V external 3V3-E 3V3_Ext supply Chip select Chip select Clock SPI_3 Master Input Slave MISO...
- Page 37 UM3350 AutoDevKit ecosystem AEK-MCU-C4MINI AEK-MCU-C4MINI Interface MCU pad MCU pin number Functionality Connector pin label SPI master input MISO slave output (MISO) SPI_0 SPI master output MOSI slave input (MOSI) CN12 3.3V external 3V3-E 3V3_Ext supply 5V-E 5V_Ext 5V external supply Ground I2C serial clock CN13...
-
Page 38: How To Configure Spi Protocol In Autodevkit Studio To Use The Aek-Mcu-C4Mini1
General purpose PF13 General purpose PE14 2.3.1 How to configure SPI protocol in AutoDevKit Studio to use the AEK-MCU-C4MINI1 with a functional board. Step 1. Table 1. Pins and related configurations, identify which SPI connector to use (for example, CN14 associated with SPI_7). -
Page 39: Figure 46. Low-Level Drivers
UM3350 AutoDevKit ecosystem Step 2. AutoDevKit Studio, select the low-level drivers from the Project explorer section. Figure 46. Low-level drivers Step 3. In the Outline tab, select “Enabled drivers”. Figure 47. Enabled drivers UM3350 - Rev 1 page 39/79... -
Page 40: Figure 48. Spi Driver Enablement
UM3350 AutoDevKit ecosystem Step 4. In the “Application configuration” window, tick the SPI checkbox. Figure 48. SPI driver enablement Step 5. In the “Outline” tab, double-click on “DSPI and I2S settings”. Figure 49. DSPI and I2S settings UM3350 - Rev 1 page 40/79... -
Page 41: Figure 50. Spi Selection
UM3350 AutoDevKit ecosystem Step 6. In the “Application configuration” window, in the “Select” section, select the SPI related to the selected connector (CN14 is related to SPI7). Figure 50. SPI selection Step 7. Scroll down from the same window and, in the ''SPI Configurations'' section, click on the green + icon. Figure 51. -
Page 42: Figure 52. Spi Configuration
UM3350 AutoDevKit ecosystem Step 8. Double-click on the newly created row to open the ''Application Configuration'' and configure the SPI according to your application needs. Figure 52. SPI configuration Step 9. Click on the “Save all” icon. Figure 53. Saving your configuration UM3350 - Rev 1 page 42/79... -
Page 43: Figure 54. Application Code Generation
UM3350 AutoDevKit ecosystem Step 10. Generate your application code. Figure 54. Application code generation Step 11. Open your main.c file under the Project Explorer and implement your application. Figure 55. Application implementation UM3350 - Rev 1 page 43/79... -
Page 44: Available Demos For Aek-Mcu-C4Mini1
7. AEK_MCU_C4MINI-MainEcuForBLDCControl-L9908 – Test Application The aim of these demos is to show how to use the AEK-MCU-C4MINI1 board and to facilitate its first usage, bearing in mind that currently, to use the functional boards of the AutoDevKit ecosystem, it is necessary to start from these demos and, if necessary, modify them according to the specifications required by the application to be implemented. -
Page 45: How Import A Demo For Aek-Mcu-C4Mini1
UM3350 How import a demo for AEK-MCU-C4MINI1 How import a demo for AEK-MCU-C4MINI1 To import a demo into Autodevkit Studio, follow these steps: Step 1. Click on the icon Import samples from application library Figure 56. Starter action tab Step 2. -
Page 46: Figure 58. Import Application Wizard Step2
Import application wizard step2 Step 4. The selected project is now imported to the Project Explorer Tab, select SPC58ECxx Platform Componnet RLA and compile the project and download it to the AEK-MCU-C4MINI1. Figure 59. AutoDevKit Studio main screen UM3350 - Rev 1... -
Page 47: Schematic Diagrams
Schematic diagrams Figure 60. AEK-MCU-C4MINI1 circuit schematic (1 of 12) AEK-MCU-C4MINI1_uC_Power Management AEK-MCU-C4MINI1_Part 1_Power Management AEK-MCU-C4MINI1_Ext_Power Management AEK-MCU-C4MINI1_Full_Bridge AEK-MCU-C4MINI1_HS_Drivers AEK-MCU-C4MINI1_uC_Power Management.SchDoc AEK-MCU-C4MINI1_Part 1_Power Management.SchDoc AEK-MCU-C4MINI1_Ext_Power Management.SchDoc AEK-MCU-C4MINI1_Full_Bridge.SchDoc AEK-MCU-C4MINI1_HS_Drivers.SchDoc Internal Supply Internal Supply HS_DRIVER1 FULL_BRIDGE HS_DRIVER2 AEK-MCU-C4MINI1_Chorus_Part 2_IO Signals AEK-MCU-C4MINI1_Output Connector AEK-MCU-C4MINI1_Chorus_Part 2_IO Signals.SchDoc... -
Page 48: Figure 61. Aek-Mcu-C4Mini1 Circuit Schematic (2 Of 12)
Figure 61. AEK-MCU-C4MINI1 circuit schematic (2 of 12) 12V_PSU 12V_uC VBatt_uC TP10 TP11 DC Switch 5V_ADC_uC LD1117S50TR STL42P4LLF6 12V_uC 5V_ADC_uC Closed Vout 5V_ADC_uC 5V - 150mA (max) Closed 10uF 10uF 100nF 100nF SMAJ24A MMBZ5242BLT1G 22uF 100nF Closed VDC_1_uC 220uF 100nF... -
Page 49: Figure 62. Aek-Mcu-C4Mini1 Circuit Schematic (3 Of 12)
Figure 62. AEK-MCU-C4MINI1 circuit schematic (3 of 12) VDD_HV_ADC VDD_HV_ADC Pin 42 Pin 44 VSS_HV_ADR_S VDD_HV_ADR_S VDD_HV_ADC 10nF 100nF 1.5uF 10nF 100nF 1.5uF VSS_HV_ADV_S VDD_HV_ADV_S A_GND OSC & JTAG (3.3V or 5V) Pin 83 VSS_HV_OSC VDD_HV_OSC GND_OSC VDD_HV_IO_Main VDD_HV_IO_MAIN 10nF... -
Page 50: Figure 63. Aek-Mcu-C4Mini1 Circuit Schematic (4 Of 12)
Figure 63. AEK-MCU-C4MINI1 circuit schematic (4 of 12) CON1 JTAG PA[0] PE[0] PB11 PA[1] PE[1] BTN1 GPIO5 PB10 PA[2] PE[2] BTN2 GPIO4 PA[3] PE[3] BTN3 GPIO3 JTAG PA[4] PE[5] BTN4 ADC9 JCOMP PG14 CON1 JCOMP PA[5] JTAG-NTRST_PD (JCOMP) PE[6] BTN5... -
Page 51: Figure 64. Aek-Mcu-C4Mini1 Circuit Schematic (5 Of 12)
Figure 64. AEK-MCU-C4MINI1 circuit schematic (5 of 12) 3V3_USB TCK_O USB_JTAG VCCIO ADBUS0 Direction A->B TDI_O USB_TDI VCCIO ADBUS1 FT2232H->Micro USB_TDI TDO_I USB_TDO VCCIO ADBUS2 3V3_USB VCIO USB_TDO TMS_IO VCCA VCCB USB_TCK VCCIO ADBUS3 3V3_USB USB_TCK TMS_IO USB_SRST# ADBUS4 USB_TX... -
Page 52: Figure 65. Aek-Mcu-C4Mini1 Circuit Schematic (6 Of 12)
Figure 65. AEK-MCU-C4MINI1 circuit schematic (6 of 12) USB_JTAG USB_TDI Closed USB_TDI USB_TDO Closed USB_TDO USB_TCK SB10 Closed USB_TCK USB_TMS SB11 Closed USB_JTAG USB_TMS USB_SRST# SB12 Closed USB_SRST# USB_TRST# SB13 Closed USB_TRST# SB14 Closed JTAG JTAG JCOMP RESET JCOMP VDD_HV_IO_Main JTAG Port N.M. -
Page 53: Figure 66. Aek-Mcu-C4Mini1 Circuit Schematic (7 Of 12)
Figure 66. AEK-MCU-C4MINI1 circuit schematic (7 of 12) VDD_HV_IO_MAIN 3V3_uC C112 C113 C114 C115 C116 5V_uC 100nF 100nF 100nF SB18 Closed 5V_uC CN15 B_PE3 VCCB B_PK14 TFT_Reset Reset B_WR_DC TFT_D/C B_PK0 SDI (MOSI) B_PK1 TFT_BckLight LED Backlight Display B_PE2 A_PK14... -
Page 54: Figure 67. Aek-Mcu-C4Mini1 Circuit Schematic (8 Of 12)
Figure 67. AEK-MCU-C4MINI1 circuit schematic (8 of 12) C124 C125 100nF 100nF VDD_HV_IO_MAIN 5V_uC TP21 CAN_0_L_DNP CAN_0_L N.M. STBY CANL C126 CN17 PD14 SB25 Closed 60.4 CAN0 TX C127 47pF 60.4 4.7nF C128 PD15 SB26 Closed CAN0 RX CAN0_Out ACT45B-510-2P... -
Page 55: Figure 68. Aek-Mcu-C4Mini1 Circuit Schematic (9 Of 12)
Figure 68. AEK-MCU-C4MINI1 circuit schematic (9 of 12) 12V_Ext TP27 TP28 12V_Ext 5V-ADC LD1117S50TR JP12 12V_Ext SB31 Closed 12V_PSU Vout 5V_ADC_Ext 5V - 150mA (max) (5V-ADC) Closed C142 C143 C144 C145 C146 C147 10uF 10uF DC Switch 100nF 100nF 22uF... -
Page 56: Figure 69. Aek-Mcu-C4Mini1 Circuit Schematic (10 Of 12)
Figure 69. AEK-MCU-C4MINI1 circuit schematic (10 of 12) 12V_PSU 18uH C178 4.7uF R138 R139 R140 R141 BSS84Q Green&Red R_PU R142 R143 BSS138Q R144 DRAIN_LSDA DRAIN_LSDB R145 R146 GNDA GNDB BC847 BC847 GNDA GNDB GNDA GNDB GNDA GNDB GNDA GNDB DRAIN_LSDA... -
Page 57: Figure 70. Aek-Mcu-C4Mini1 Circuit Schematic (11 Of 12)
Figure 70. AEK-MCU-C4MINI1 circuit schematic (11 of 12) 12V_PSU R163 C192 R164 100nF BSS84Q R165 BSS138Q TP46 R166 R167 R168 INPUT0 OUTPUT0 5.1K R169 FAULRST OUTPUT0 TP47 R170 HS_DRIVER1 OUTPUT0 INPUT0 OUTPUT0 TP49 HS_DRIVER1 SEL0 R171 SEL0 OUTPUT1 INPUT1 OPEN_LOAD... -
Page 58: Figure 71. Aek-Mcu-C4Mini1 Circuit Schematic (12 Of 12)
Figure 71. AEK-MCU-C4MINI1 circuit schematic (12 of 12) CON1 CON5 DSPI1 PB11 PD10 GPIO5 GPIO1 DSPI1 CS1 PB10 PC11 GPIO4 ADC6 DSPI1 CS2 GPIO3 ADC5 DSPI1 CLK PC10 ADC9 TIMER2 DSPI1 MISO CON1 CON5 DSPI1 ADC8 TIMER1 DSPI1 MOSI PD11... -
Page 59: Board Versions
AEK-MCU-C4MINI1 versions Finished good Schematic diagrams Bill of materials AEK$MCU-C4MINI1A AEK$MCU-C4MINI1A schematic diagrams AEK$MCU-C4MINI1A bill of materials 1. This code identifies the AEK-MCU-C4MINI1 evaluation board first version. It is printed on the board PCB. UM3350 - Rev 1 page 59/79... -
Page 60: Bill Of Materials
UM3350 Bill of materials Bill of materials Table 3. AEK-MCU-C4MINI1 bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code C1, C4, C7, C9, C11, C13, C15, C17, C19, C20, C24, 0603 - 50V - 10nF 885012206089 C26, C28,... - Page 61 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code 1206 - 25V - C3, C6 1.5uF 885012208065 X7R Class II C22, C31, 1206 - 25V - 2.2uF 885012208066 X7R Class II C23, C25, C27, C29, 0603 - 50V - 47nF 885012206093 C97, C106,...
- Page 62 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code C91, C101, 0603 - 50V - 68pF 885012006056 C156 NP0 Class I C98, C107, 0603 - 50V - 220pF 885012206079 C165, C176 X7R Class II C126, C128, 0603 - 50V - C131, 47pF 885012006055...
- Page 63 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code D15, D34, 0805 - Led 150080RS75000 Red - 2V D16, D17, 0805 - Led D18, D19, Amber 150080AS75000 Amber - 2V Standard GF1A Rectifier, 50V, Onsemi GF1A 0603 - Bi- color Chip Green&Red LED Compact...
- Page 64 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code 3.50mm - WR-TBL Series 1031 Horizontal J5, J6 691103110002 691103110002 Entry Modular, THT, pitch 3.5mm, 5.00mm - WR-TBL 691502710002 Serie 5027 691502710002 Horizontal Entry Modular 5.00mm - WR-TBL Series 5027 - Horizontal J8, J9...
- Page 65 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code Semi-shielded Power 18uH Bourns SRN1060-180M Inductor - 9.8x10 - 3.8A 2.54mm - WR-PHD Pin Header, THT, N.M. N.A. pitch 2.54mm, Single Row, Vertical, 4p Mini USB 2.0 Type B, 65100516121 / Receptable, 65100516121 /...
- Page 66 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code R4, R5, R6, R7, R8, R9, R10, R11, R12, R13, R17, R18, R29, R37, R43, R75, R76, R77, R78, R79, R80, R106, R116, R147, R148, R193, R194, R195, SB1, SB2, SB3, SB4, SB5, SB6, SB7,...
- Page 67 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code R16, R24, R39, R44, R50, R52, R59, R66, R67, R71, R72, R73, R74, R86, R87, R88, R89, R90, R117, R118, 0603 - ±1% - R123, 0.2W, 0603 - Panasonic ERJP03F1002V R125,...
- Page 68 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code R60, R133, R145, R146, R167, R169, R170, R171, 0603 - ±1% - Panasonic ERJ-PA3F1502V R172, 0.25W R173, R183, R184, R185, R186, R187, R188 R70, R81, 0603 - ±1% - R82, R83, Panasonic ERJPA3F6800V...
- Page 69 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code Single-Bit Dual-Supply U3, U4, U6, Transceiver U7, U10, With SN74LVC1T45DCK Texas Instruments SN74LVC1T45DCK U11, U12, Configurable Voltage Translation and 3-State Outputs Automotive USBLC6-2SC6Y, protection for USBLC6-2SC6Y SOT23-6L high speed interfaces.
- Page 70 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code SN74LXC8T2 45 8-bit Dual- Supply Bus Transceiver SN74LXC8T245 with Texas Instruments SN74LXC8T245 Configurable Level Shifting and 3-State Outputs SN74LXC2T4 5 Dual-Bit Dual-Supply SN74LXC2T45 Texas Instruments SN74LXC2T45 Transceiver with Configurable Level Shifting CAN FD...
- Page 71 UM3350 Bill of materials Item Q.ty Ref. Part/value Description Manufacturer Order code WA-SPAII Plastic Spacer Stud, for blister 970150365 970150365 metric, internal/ internal WR-WTB 2.54 mm for blister 61900811621 Female 61900811621 Terminal Housing WR-WTB 2.54 mm for blister 61900211621 Female 61900211621 Terminal Housing...
-
Page 72: Regulatory Compliance Information
UM3350 Regulatory compliance information Regulatory compliance information Notice for US Federal Communication Commission (FCC) For evaluation only; not FCC approved for resale FCC NOTICE - This kit is designed to allow: (1) Product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and (2) Software developers to write software applications for use with the end product. -
Page 73: Revision History
UM3350 Revision history Table 4. Document revision history Date Revision Changes 19-Jun-2024 Initial release. UM3350 - Rev 1 page 73/79... -
Page 74: Table Of Contents
How import a demo for AEK-MCU-C4MINI1 ........ - Page 75 UM3350 Contents Board versions ..............59 Bill of materials .
-
Page 76: List Of Tables
AEK-MCU-C4MINI1 bill of materials ........ -
Page 77: List Of Figures
AEK-MCU-C4MINI1 evaluation board, top view: main components ....... . 3... - Page 78 AEK-MCU-C4MINI1 circuit schematic (10 of 12) ........
