! IMPORTANT SAFETY GUIDE
Your safety and the safety of others is very important.
•
In order to help you make informed decisions about safety, we have provided the
•
following warnings, safety precautions, installation instructions, and other important
information to alert you to potential hazards that could hurt you or others.
Please do a job safety analysis before each task to identify potential hazards for your
•
situation and remove/protect against them.
Use own good judgment and take your time.
•
Check packaged materials immediately upon arrival to ensure that all listed parts are
•
included and undamaged.
Read and understand all warnings, safety precautions, and instructions before installing
this product.
SENSORS FIELD OF VIEW WILL BE ALTERED WITH USE OF THE
REPLACEMENT BUMPER.
•
FAILURE TO OBSERVE THE FOLLOWING WARNINGS AND
INSTRUCTIONS PROVIDED IN THIS MANUAL COULD LEAD TO
SEVERE INJURY AND/OR DEATH.
FOR PROFFESIONAL INSTALLATION ONLY. CARELESS
•
INSTALLATION AND/OR OPERATION CAN RESULT IN SERIOUS
INJURY, DEATH, AND/OR EQUIPMENT DAMAGE. ALL LIABILITY FOR
INSTALLATION AND USE RESTS WITH THE USER OR CONSUMER.
FAB FOURS, INC. ONLY APPROVES INSTALLING THIS PRODUCT
•
ACCORDING TO THESE WRITTEN INSTRUCTIONS WITH THE
HARDWARE PROVIDED. FAILURE TO INSTALL ACCORDING TO
THESE INSTRUCTIONS WILL INVALIDATE THE WARRANTY. THIS
INCLUDES, BUT IS NOT LIMITED TO, USING ALTERNATIVE
INSTALLATION METHODS, HARDWARE, OR MATERIALS.
THIS PRODUCT IS FOR OFFROAD USE ONLY.
•
Copyright 2011 Fab Fours, Inc.
Installation Instructions
WARNINGS
Page 1 of 12
Jeep JL Front Bumper
Product Number: B4652
Application: '18+ JEEP JL
B4652
Advertisement
Table of Contents
Related Manuals for Fab Fours B4652
Summary of Contents for Fab Fours B4652
- Page 1 INSTALLATION AND/OR OPERATION CAN RESULT IN SERIOUS INJURY, DEATH, AND/OR EQUIPMENT DAMAGE. ALL LIABILITY FOR INSTALLATION AND USE RESTS WITH THE USER OR CONSUMER. FAB FOURS, INC. ONLY APPROVES INSTALLING THIS PRODUCT • ACCORDING TO THESE WRITTEN INSTRUCTIONS WITH THE HARDWARE PROVIDED.
-
Page 2: Safety Precautions
Always insulate and protect all exposed wiring and electrical terminals. o Perform regular inspections and maintenance on mounts and hardware. o Tire may rub at max turn or articulation. Page 2 of 12 B4652 Copyright 2011 Fab Fours, Inc. - Page 3 This bumper has been engineered for strength while reducing weight. Your bumper was designed, CNC laser cut, fabricated, and powder coated… all in the U.S.A. Enjoy the fit and finish of a quality JL front bumper from Fab Fours Inc! Page 3 of 12 B4652...
-
Page 4: Tools Required
1. Remove the 2 push pin fasteners attaching the closeout panel to the frame. 2. Remove 2 bolts attaching the plastic skid plate to lower frame. 3. Disconnect fog light harness located on passenger side frame rail (if equipped). Page 4 of 12 B4652 Copyright 2011 Fab Fours, Inc. - Page 5 Installation Instructions Jeep JL Front Bumper Product Number: B4652 Application: ‘18+ JEEP JL 4. Remove (8) nuts from studs using 18mm socket. 5. Remove OEM bumper and set aside. Page 5 of 12 B4652 Copyright 2011 Fab Fours, Inc.
- Page 6 If light bar or light pods are to be used; drill the respective holes in the cover plate using the hole pattern on the underside before install. Page 6 of 12 B4652 Copyright 2011 Fab Fours, Inc.
-
Page 7: Wire Colors
Black White 3. Tuck the Fab Fours provided wiring and bulb out of the way until the installation of the Fab Fours bumper is complete. 4. Tap into OEM fog light harnesses on each side of the vehicle using two supplied tap connectors. - Page 8 Use washers only on the nut side (inside the bumper). Use needle nose pliers to tighten nuts with limited access. Figure 2 – Light Insert Installation Page 8 of 12 B4652 Copyright 2011 Fab Fours, Inc.
- Page 9 Product Number: B4652 Application: ‘18+ JEEP JL 9. Install the Fab Fours fog lights onto the mounting brackets as shown below using the #8 button head screws, washers, and nylock hex nuts. Figure 3 - Fog Light to Bracket Installation 10.
-
Page 10: Bumper Installation
Secure loosely with supplied 7/16” flat washers, lock washer and nut. Do not tighten fully. Because of the mounting system, little adjustment is necessary. Verify proper alignment and tighten all fasteners. Page 10 of 12 B4652 Copyright 2011 Fab Fours, Inc. -
Page 11: Maintenance & Care
Stripped, fractured, or bent bolts or nuts need to be replaced. VIII. Contact Information Fab Fours Inc. Phone (866)-385-1905 2213 Industrial Park Rd. (866)-574-1424 Lancaster, SC 29720 Email Support@fabfours.com Page 11 of 12 B4652 Copyright 2011 Fab Fours, Inc. - Page 12 Installation Instructions Jeep JL Front Bumper Product Number: B4652 Application: ‘18+ JEEP JL More than expected… Better than expected Page 12 of 12 B4652 Copyright 2011 Fab Fours, Inc.
