Operation

To move the cursor, turn the control knob to the left
or the right. The marked position is white and/or has
a turned up tab.
Selecting menu
To advance in the menu system select a main menu
window then opens with sub menus.
Select one of the sub menus by marking it and then
pressing the OK button.
Selecting options
In an options menu the current selected op-
tion is indicated by a green tick.
1. Mark the applicable option. One of the
options is pre-selected (white).
2.
lected option. The selected option has a
green tick.
Setting a value
1. Mark the value you want to set using the
control knob.
2. Press the OK button. The background of
the value becomes green, which means
that you have accessed the setting mode.
3. Turn the control knob to the right to in-
crease the value and to the left to reduce
the value.
4.
you have set. To change and return to the
original value, press the Back button.
HT 6Split
HT 12Split
-
Values to be changed
Use the virtual keyboard
Różne klawiatury
In some menus where text may require entering, a
virtual keyboard is available.
Różne klawiatury
Depending on the menu, you can gain access to dif-
ferent character sets which you can select using the
control knob. To change character table, press the
Back button. If a menu only has one character set the
keyboard is displayed directly.
the OK button.
Scroll through the windows
trol knob to scroll between the windows.
Current menu window
Scroll through the windows in the start guide
1. Turn the control knob until one of the arrows in
the top left corner (at the page number) has been
marked.
2. Press the OK button to skip between the steps in
the start guide.
Help menu
In many menus there is a symbol that indicates
that extra help is available
1. Use the control knob to select the help symbol.
2. Press the OK button.
The help text often consists of several windows that
you can scroll between using the control knob.
Number of windows in the menu
Chapter 8 | | Control - Introduction
-
