5 Outdoor unit LSplit

Transport and storage

LSplit must be transported and stored vertically.
IMPORTANT
Ensure that the heat pump cannot fall over during trans-
port.

Assembly

• Place LSplit outdoors on a solid level base that
can take the weight, preferably a concrete foun-
dation. If concrete slabs are used they must rest
on asphalt or shingle.
• The concrete foundation or slabs must be posi-
tioned so that the lower edge of the evaporator
is at the level of the average local snow depth;
however, a minimum of 300 mm. Stands and at-
tachments on the page are available in the LSplit
• LSplit should not be positioned next to noise sen-
sitive walls, for example, next to a bedroom.
•
venience the neighbours.
• LSplit must not be placed so that recirculation of
the outdoor air can occur. This causes lower out-
• The evaporator should be sheltered from direct
function. Place LSplit protected from wind against
the evaporator
• Large amounts of condensation water, as well
as melt water from defrosting, can be produced.
similar (see page13).
• Care must be exercised so that the heat pump is
not scratched during installation.
Do not place LSplit directly on the lawn or other non
solid surface.
HT 6Split
HT 12Split
If there is a risk of snow slip from roof, a protective
roof or cover must be erected to protect the heat
pump,pipes and wiring.
Lift from the street to the set up
-
location
If the base allows, the simplest thing is to use a pallet
truck to move the LSplit to the set up location.
IMPORTANT
the packaging).
If LSplit needs to be transported across soft ground,-
such as a lawn, we recommend that a crane truck is
used that can lift the unit to the installation location.
When LSplit is lifted with a crane, the packaging must
be undamaged and the load distributed with a boom,-
XX mm 300 mm
see the illustration above.
If a crane cannot be used LSplit can be transported
LEK
using an extended sack truck. LSplit must be used
on the side marked "heavy side" and two people are
required to get the LSplit up.
Chapter 5 | Outdoor unit LSplit 19
