ULOW/MESH/RAILS - Solite Pro Ultra Low Mesh Side Rails
Instructions For Use
This document is to be used in conjunction with the full bed instructions
for use document, please see INSTRUC/ULOW. Read all warnings prior
to using this guide.
1. Assembly/Disassembly
Build one side of the side rails following the process below, before repeating this process for the other side.
1
"CLICK"
(x 2) Left Hand
Channels
1. Locate fixings pack and side rail channels,
please note channels are handed. Slide the
channel finger up into the raised position,
locking into place with a 'click'.
3
3
3. Fix both the left and right channels to bottom rail
using the fixings provided, (x 2) per side.
5
5. Repeat steps 1 to 4 for the remaining side rail, you will then have two fully assembled side
rails ready to fit to the bed. Both side rails should move up and down freely, see section 2 for
operation and INSTRUC/ULOW for instructions on how to fit the side rails to the bed.
Drive DeVilbiss Sidhil Ltd.
INSTRUC/ULOW/MESH/RAIL
(x 2) Right Hand
Channels
| Solite Pro Ultra Low Mesh Side Rails
| 2023/04 rev0
2
2. Un- roll and lay flat the side rail mesh, clear
buttons on the side rail mesh should be facing
upwards as shown. Align the left hand channel to
the left hand side of the side rail mesh, sliding the
channel finger into the top rail, repeat this for the
right hand side.
4
4. Attach the side rail mesh to
both channels, place all (x 6) clear
buttons through the straps on both
channels. You may need to slide
each strap up or down within the
channel to ensure it can be placed
over the button.
