100m 4K 60 4:4:4 HDBaseT 3.0 Extender with eARC
EX3-100-EARC
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior
to starting the installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
• Read through the
Wiring and Connections
guidelines before creating or choosing pre-made cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
Basic Wiring Diagram
Control System
Copyright © 2024 WyreStorm ProAV Corporation |
EX3-100-EARC Quickstart Guide | 240812
section for important wiring
Laptop
Display Device
wyrestorm.com
In the Box
1x EX3-100-EARC
1x 12V Power Supply (US/UK/EU/AU)
1x IR Receiver Cable
1x IR Emitter Cable
4x Mounting Ears with screws
2x 3-pin Phoenix Connector
1x Quickstart Guide (This Document)
Router
Amplifier
KEY
HDMI
HDBaseT
Control
Digital Audio
