Description
Internal Channel
Temperature Sensor
Internal Channel
Temperature Resolution
Internal Channel Accuracy
Remote Channel
Temperature Sensor
Remote Channel Range
Remote Channel Resolution
Remote Channel Accuracy
Cold Junction Compensation
Channels
500,000 readings; 250,000 readings in multiple start/stop mode or
Memory
Wrap Around
Reading Rate
1 reading every second up to 1 reading every 24 hours
LED Indicator
Required Interface Package
Baud Rate
Typical Battery Life
Operating Environment
–20 °C to +80 °C (-4 °F to +176 °F), 0 %RH to 95 %RH non–condensing
Material
Data Logger: 1.4 in x 2.2 in x 0.6 in (36 mm x 56 mm x 16 mm)
Waterbox: 3.66 in x 2.45 in x 0.93 in (93 mm x 62 mm x 24 mm)
Dimensions
Thermocouple Wire: 24 gauge, 30 inches (762 mm)
Thermocouple Probe: 6 in x 1/8 in dia. (153 mm x 3.2 mm)
Weight
Approvals
If using a stainless steal braided thermocouple please note that the water can wick into the waterbox through the
cable and cause damage to the data logger. MadgeTech recommends mounting the box above the thermocouple
so that the water wicks away from the waterbox and data logger, or use epoxy to seal the thermocouple around the
compression fitting.
BATTERY WARNING
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE, FORCE OVER
DISCHARGE, DISASSEMBLE, CRUSH, PENETRATE OR INCINERATE. BATTERY MAY LEAK OR EXPLODE IF HEATED
ABOVE 80°C (176°F).
Specifications subject to change.
See MadgeTech's terms and conditions at www.madgetech.com
MadgeTech, Inc.
6 Warner Road
Phone 603.456.2011
www.madgetech.com
ETR101A
Semiconductor
0.1 °C (0.18 °F)
+0.25 °C (+0.45 °F)
Thermocouple Type K
-260 °C to +899 °C
0.1°C
±2.0
Automatic
1 internal & 1 remote
trigger settings mode
Yes
Red and Green
IFC200
115,200
10 years at a 15 minute reading rate
ABS plastic
Complete Kit: 9.5 oz (269 g)
CE
Warner, NH 03278
l
Fax 603.456.2012
l
info@madgetech.com
l
DOC-1228035-00 REV 16 2014.09.22
Product User Guide
ETR101A
Exhaust Temperature Data Logging System
ETR101A
To view the full MadgeTech product line,
visit our website at
www.madgetech.com.
