INSTALLATION INSTRUCTIONS
33116T-4
33117T-4
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication.
Kohler Co. reserves the right to make changes in product characteristics, packaging, or availability at any time
without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. An inline water filter must be used with this product.
3. Do not remove the rubber protector from the valve body until instructed to.
4. Install valve 78980T-BDR according to the rough-in dimensions of 33117T-4, install valve 78981T-BDR
according to the rough-in dimensions of 33116T-4.
5. All installations should comply with the relevant requirements of AS/NZS 3500.
ROUGH-IN DIMENSIONS
1486786-A2-A
Recessed Shower Slim Trim
Recessed Bath Shower Slim Trim
100
The finished wall
100
The finished wall
3.5
32~52
89
47~67
3.5
32~52
89
45~65
ACCLIV
33116T-4
33117T-4
1
