- Page 1 Installation Instructions Freestanding Bath Record your model number: Noter le numéro de modèle: Anote su número de modelo: Français, page 8 Español, página 14 1476139-2-A...
-
Page 2: Warranty
Warranty This product is covered under the KOHLER Plastic Baths and Receptors Lifetime Limited Warranty, found at ® kohler.com/warranty. For a hardcopy of warranty terms, contact the Customer Care Center. Tools and Materials 100% Silicone Sealant Sealant Tape Plus: • Drop Cloth •... - Page 3 Install the bath to an adequately supported, level finished floor. This bath is designed for freestanding installation only. This bath features an integral overflow. Install a floor- or ceiling-mount bath filler with this freestanding bath. This bath conforms to CSA B45.5/IAPMO Z124. 1476139-2-A Kohler Co.
-
Page 4: Prepare The Site
Insert the drain body into the bath. Thread on a 1-1/2" 11-1/2 NPSM PVC adapter. Measure the distance "X" between the bottom of the adapter and the floor. Cut the pipe to extend "X" height above the floor. 1476139-2-A Kohler Co. - Page 5 Apply 100% silicone sealant to both sides of the drain gasket. Apply sealant tape to the drain flange threads. Install the drain flange to the bath. Install the drain gasket and washer. Secure the drain flange with the nut. 1476139-2-A Kohler Co.
- Page 6 Carefully set the bath on the desired location. Adjust the bath position as needed to ensure that the drain pipe is centered in the bath drain hole. Verify that the bath is level. Loosen the nuts to adjust the bath feet, as needed. 1476139-2-A Kohler Co.
-
Page 7: Complete The Installation
If desired, apply a thin, continuous bead of clear or color-matched silicone sealant to the seam between the bath and the finished floor. Install the bath filler following the faucet manufacturer’s instructions. Close the bath drain. Fill the bath to the overflow and check the drain connections for leaks. 1476139-2-A Kohler Co.
