micro-ATX Motherboard Supports LGA1700 12th/13th Gen. Intel®
Core™ i9/i7/i5/i3, Pentium® and Celeron® Processor, DDR4,
Triple Independent Display, Dual 2.5GbE LAN, M.2,
USB 3.2, SATA 6Gb/s, HD Audio and RoHS
Quick Installation Guide
Package List
IMB-ADL-Q670 package includes the following items:
1 x IMB-ADL-Q670 single board computer
2 x SATA cable
1 x I/O shielding
1 x QIG
IMB-ADL-Q670
Version 1.0
January 10, 2023
©2023 Copyright by IEI Integration Corp.
All rights reserved.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology IMB-ADL-Q670
Summary of Contents for IEI Technology IMB-ADL-Q670
- Page 1 USB 3.2, SATA 6Gb/s, HD Audio and RoHS IMB-ADL-Q670 Quick Installation Guide Version 1.0 January 10, 2023 Package List IMB-ADL-Q670 package includes the following items: 1 x IMB-ADL-Q670 single board computer 2 x SATA cable 1 x I/O shielding ...
-
Page 2: Specifications
Specifications CPU: LGA1700 12 Generation Intel® Core™ i9/i7/i5/i3, Celeron® and Pentium® processors (up to 125W TDP) Chipset: Intel® Q670/Q670E Memory: Four 288-pin 3200MHz dual-channel unbuffered DDR4 SDRAM DIMM slots supporting up to 128 GB memory BIOS: AMI UEFI BIOS ... - Page 3 Front Panel: 1 x Front panel (2x7 pin, p=2.54; power LED, HDD LED, speaker, power button, reset button) LAN LED: 2 x LAN LED (1x2 pin, p=2.54) Expansions: 1 x PCIe Gen5 x16 slot 2 x PCIe Gen4 x4 open-end slot 1 x PCIe Gen3 x1 slot 1 x M.2 M key (2242/2280, PCIe x4), NVMe supported 1 x M.2 M key (2242/2280, PCIe x2 for SSD), NVMe supported...
-
Page 4: Ordering Information
All the drivers and utility for the IMB- https://download.ieiworld.com ADL-Q670 are available on IEI Resource Download Center. Type IMB-ADL-Q670 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to... -
Page 5: Jumpers Setting And Connectors
Jumpers Setting and Connectors LABEL FUNCTION J_ATX_AT1 AT/ATX power mode setting J_CMOS1 Clear CMOS jumper FRONT-PANEL1 Audio connector ATX1 ATX power connector CPU12V1 ATX CPU 12V power connector BAT2 RTC battery connector CHASSIS1 Chassis intrusion connector CHA_DIMM0, CHA_DIMM1, DDR4 DIMM slots CHB_DIMM0, CHB_DIMM1 DIO1 Digital I/O connector... - Page 6 LAN1_USB1, LAN2_USB2 External 2.5GbE RJ-45 and dual USB 10Gb/s combo connector USB5 External quad USB 2.0 connector USB4 External dual USB 5Gb/s connector USB3 External quad USB 5Gb/s connector J_ATX_AT1: AT/ATX Power Mode Setting PIN NO. DESCRIPTION Short A - B ATX Power Mode (default) Short B - C AT Power Mode...
- Page 7 ATX1: ATX Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V -12V PS_ON Power good 5VSB +12V +12V +3.3V CPU12V1: ATX CPU 12V Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V DIO1 : Digital Input/Output Connector PIN NO.
- Page 8 DEBUG_1: EC Debug Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION EDICLK EDICS EDIDI EDIDO CPU_FAN1: CPU Fan Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FANIO PWM (+5V) SYS_FAN1: System Fan Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V FANIO PWM (+5V) F_PANEL1: Front Panel Connector DESCRIPTION...
- Page 9 JLAN_LED1: LAN1 Link LED Connector DESCRIPTION DESCRIPTION +3.3V I225_LINK_ACT_N_1 JLAN_LED2: LAN2 Link LED Connector DESCRIPTION DESCRIPTION +3.3V I225_LINK_ACT_N_2 COM3-6: RS-232 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION DCD3 DSR3 RXD3 RTS3 TXD3 CTS3 DTR3 GND3 GND3 DCD4 DSR4 RXD4 RTS4 TXD4...
- Page 10 COM7-10: RS-232 Serial Port Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION DCD7 DSR7 RXD7 RTS7 TXD7 CTS7 DTR7 GND7 GND7 DCD8 DSR8 RXD8 RTS8 TXD8 CTS8 DTR8 GND8 GND8 DCD9 DSR9 RXD9 RTS9 TXD9 CTS9 DTR9 GND9 GND9 DCD10 DSR10 RXD10 RTS10 TXD10...
- Page 11 SATA1, SATA2, SATA3, SATA4: SATA 6Gb/s Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX‐ SATA_TX+ SATA RX+ SATA_TX‐ J_SMB1: SMBus Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SMB_CLK SMB_DATA JSPI1: Flash SPI ROM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V SPI_CLK SPI_CS#...
- Page 12 PCIE_4_RX_DP NGFF1_ACT_N PCIE_4_TX_DN4 +3.3V PCIE_4_TX_DP4 +3.3V +3.3V PCIE_3_RX_DN +3.3V PCIE_3_RX_DP PCIE_3_TX_DN3 PCIE_3_TX_DP3 PCIE_2_RX_DN PCIE_2_RX_DP PCIE_2_TX_DN2 PCIE_2_TX_DP2 M_2_SSD_SLP PCIE_1_RX_DN PCIE_1_RX_DP PCIE_1_TX_DN1 PCIE_1_TX_DP1 PLT_RST_N SRCCLKREQB_17_N PCIE_SRC17_DN PCIE_SRC17_DP +3.3V +3.3V +3.3V...
- Page 13 M2_M2: M.2 M-key Slot PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V EXP_A_RX_19_DN EXP_A_RX_19_DP NGFF2_ACT_N EXP_A_TX_19_C_DN +3.3V EXP_A_TX_19_C_DP +3.3V +3.3V EXP_A_RX_18_DP +3.3V EXP_A_RX_18_DN EXP_A_TX_18_C_DN EXP_A_TX_18_C_DP EXP_A_RX_17_DN EXP_A_RX_17_DP EXP_A_TX_17_C_DN EXP_A_TX_17_C_DP M_2_SATA_SLP EXP_A_RX_16_DN EXP_A_RX_16_DP EXP_A_TX_16_C_DN EXP_A_TX_16_C_DP PERST_N SRCCLKREQB_15_N PCIE_CLK_DN15 PCIE_CLK_DP15...
- Page 14 +3.3V +3.3V +3.3V DVI1 External VGA Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION CRT_VCC CRT_PLUG# VGA_SDA 5HSYNC 5VSYNC VGA_SCL External DVI-I Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI_DATA2#1_L SHIELD_GND HDMI_DATA2-1_L HDMIC_OB_HPD SHIELD_GND HDMI_DATA0#1_L HDMI_DATA0-1_L SHIELD_GND HDMIC_OB_SCL HDMIC_OB_SDA SHIELD_GND HDMI_DATA1#1_L HDMI_CLK-1_L HDMI_DATA1-1_L HDMI_CLK#-1_L...
- Page 15 LAN1_USB1, LAN2_USB2 External Dual USB 3.2 Gen 2 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ 2.5GbE RJ-45 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_MDI0P LAN1_MDI2P LAN1_MDI0N LAN1_MDI2N LAN1_MDI1P...
- Page 16 Board Layout: Jumper and Connector Locations (Unit: mm)
