microATX Motherboard Supports LGA1700 12th/13th Gen.
Intel® Core™ i9/i7/i5/i3, Pentium® and Celeron® Processor,
DDR4, Triple Independent Display, Dual GbE LAN,
Quick Installation Guide
Package List
IMB-ADL-H610 package includes the following items:
1 x IMB-ADL-H610 single board computer
2 x SATA cable
1 x I/O shielding
1 x QIG
USB 3.2, SATA 6Gb/s, and RoHS
IMB-ADL-H610
Version 1.0
November 11, 2022
©2022 Copyright by IEI Integration Corp.
All rights reserved.
Advertisement
Related Manuals for IEI Technology IMB-ADL-H610
Summary of Contents for IEI Technology IMB-ADL-H610
- Page 1 USB 3.2, SATA 6Gb/s, and RoHS IMB-ADL-H610 Quick Installation Guide Version 1.0 November 11, 2022 Package List IMB-ADL-H610 package includes the following items: 1 x IMB-ADL-H610 single board computer 2 x SATA cable 1 x I/O shielding ...
-
Page 2: Specifications
Specifications CPU: LGA1700 12 Generation Intel® Core™ i9/i7/i5/i3, Celeron® and Pentium® processors (up to 65W TDP) Chipset: Intel® H610/H610E Memory: Two 288-pin 3200 MHz dual-channel unbuffered DDR4 SDRAM DIMM slots supporting up to 64 GB memory BIOS: AMI UEFI BIOS ... - Page 3 Audio: 1 x Analog audio (2x5 pin, p=2.0) Support 7.1 channel HD audio by IEI AC-KIT-888S kit module Front Panel: 1 x Front panel (2x7 pin, p=2.54; power LED, HDD LED, speaker, power button, reset button) LAN LED: 2 x LAN LED (1x2 pin, p=2.54) ...
- Page 4 All the drivers and utility for the IMB- https://download.ieiworld.com ADL-H610 are available on IEI Resource Download Center. Type IMB-ADL-H610 and press Enter to find all the relevant software, utilities, and documentation. To install software from the downloaded ISO file, mount the file as a virtual drive to...
-
Page 5: Ordering Information
Ordering Information IMB-ADL-H610-R10: microATX motherboard supports LGA1700 12th/13th Generation Intel® Core™ i9/i7/i5/i3, Pentium® and Celeron® processor, DDR4, triple independent display, dual LAN, USB 3.2, SATA 6Gb/s, and RoHS AC-KIT-888S-R10: Realtek ALC888S 7.1 Channel HD Audio board, RoHS ... -
Page 6: Jumpers Setting And Connectors
Jumpers Setting and Connectors LABEL FUNCTION J_ATX_AT1 AT/ATX power mode setting J_CMOS1 Clear CMOS jumper ME_FLASH1 Flash descriptor security override jumper IAUDIO Audio connector for IEI AC-KIT-888S kit ATX1 ATX power connector CPU12V1 ATX CPU 12V power connector BAT2 RTC battery connector CHASSIS1 Chassis intrusion connector CHA_DIMM1, CHB_DIMM1... - Page 7 HDMI_DP1 External HDMI and DP combo connector External 1GbE RJ-45 and dual USB 3.2 LAN1_USB1 Gen 1 combo connector External 2.5GbE RJ-45 and dual USB 3.2 LAN2_USB2 Gen 2 combo connector USB2_1 External quad USB 2.0 connector J_ATX_AT1: AT/ATX Power Mode Setting PIN NO.
- Page 8 ATX1: ATX Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +3.3V +3.3V +3.3V -12V PS_ON Power good 5VSB +12V +12V +3.3V CPU12V1: ATX CPU 12V Power Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION +12V +12V +12V +12V BAT2: RTC Battery Connector PIN NO.
- Page 9 DIO1 : Digital Input/Output Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION Output 5 Output 4 Output 3 Output 2 Output 1 Output 0 Input 5 Input 4 Input 3 Input 2 Input 1 Input 0 DEBUG_1: EC Debug Connector PIN NO. DESCRIPTION PIN NO.
- Page 10 F_PANEL1: Front Panel Connector DESCRIPTION DESCRIPTION PWR_LED+ SPKR+ SPKR PWR_LED- PWR_BTN+ SPKR- PWR_BTN- HDD_LED+ Reset+ RESET HDD_LED- Reset- J_I2C1: I C Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION I2C_CLK I2C_DATA JLAN_LED1: LAN1 Link LED Connector DESCRIPTION DESCRIPTION +3.3V LAN1_LED_LNK#_ACT JLAN_LED2: LAN2 Link LED Connector DESCRIPTION DESCRIPTION +3.3V...
- Page 11 J1: RAA229134 FW Flash Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION J2: LT86101X FW Flash Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA1, SATA2, SATA3, SATA4: SATA 6Gb/s Connectors PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA_RX‐ SATA_TX+ SATA RX+ SATA_TX‐ J_SMB1: SMBus Connector PIN NO.
- Page 12 JEC1: Flash EC ROM Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION FSCE# +3.3V FMISO EC_DET_FLASH FSCK FMOSI USB2_CN1: Internal USB 2.0 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA+ USB_DATA+ USB_DATA- COM1, COM2: External RS-232/422/485 Connectors RS-232 RS-422 RS-485 TXD422- TXD485- TXD422+...
- Page 13 HDMI_DP1 External DP Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LANE0P LANE3N LANE0N CONFIG_A_1 LANE1P CONFIG_A_2 AUXP LANE1N LANE2P AUXN LANE2N LANE3P External HDMI Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION HDMI_DATA2P HDMI_CLKN HDMI_DATA2N HDMI_DATA1P HDMI_CLK HDMI_DATA1N HDMI_SDA HDMI_DATA0P HDMI_DATA0N HDMI_HPD HDMI_CLKP...
- Page 14 LAN1_USB1 External Dual USB 3.2 Gen 1 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ 1GbE RJ-45 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN1_MD0+ LAN1_MD3+ LAN1_MD0- LAN1_MD3- LAN1_MD1+ LAN1_MD1-...
- Page 15 LAN2_USB2 External Dual USB 3.2 Gen 2 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DATA- USB_DATA- USB_DATA+ USB_ DATA+ USB3_RX- USB3_RX- USB3_RX+ USB3_ RX+ USB3_TX- USB3_TX- USB3_TX+ USB3_TX+ 2.5GbE RJ-45 Connector PIN NO. DESCRIPTION PIN NO. DESCRIPTION LAN2_MD0+ LAN2_MD3+ LAN2_MD0- LAN2_MD3- LAN2_MD1+ LAN2_MD1-...
- Page 16 Board Layout: Jumper and Connector Locations (Unit: mm)
