Record Browser; Browser Overview; Using The Browser - Extech Instruments VPC260 User Manual

7

Record Browser

7.1 Browser Overview

The meter can store up to 1,000 records, each test is automatically saved as
a record. Records include particle count, ambient measurements, and time/
date. You can export records to a spreadsheet using the PC interface, see
Section 9.

7.2 Using the Browser

To open the browser, press F1 under the browser icon and use the arrows
to scroll through the record list.
Press F1 under the trash icon to delete a highlighted record.
Press ENTER to open a highlighted record.
Press ESC to return to the Browser. A description of the test record screen is
provided below.
1. Current date and time.
2. Data log time and date.
3. Measurement unit (particles per litre, in this example).
4. Particle count channels with readings.
5. Ambient measurements.
6. Battery status.
