"Our commitment is to produce some of the finest Umbrella systems in the world –
Papillon:
The Papillon is a Dual Pole Gazebo with a unique overhead opening, closing and
storage system.
Assembly Information and Care & Maintenance instructions:
NOTE: The Papillon Roof Structure is a FREE SPINNING system.
• The Nyloc nuts must only be tightened to the point where the Nyloc nut holds firmly onto the
threaded shaft.
• Make sure that the Nyloc nuts are not tightened to the point where the rolling system and side
rollers are jammed. This would result in the inability to open and close the canopy and may re-
sult in damage to the gearbox or crank holder.
Assembly Instructions:
It is recommended to use cotton gloves when handling the canopy to avoid dirty marks
on the canvas.
1. Remove the Roof Structure & Canopy from the protective tube. The wooden end plugs are
secured using screws which must be removed to get the end plugs out.
2. Ensure that you are working in a clean area with ample space to assemble the Papillon. It is
advisable to lay the roof structure onto a clean surface as the cover bag and roof canopy
will get marks from a dirty surface. The plastic covering can be used for this purpose – you
can cut the plastic bag down the length so that the clean inner surface becomes the work-
ing surface. Make sure that you do not cut or damage the cover bag or the roof canopy
when cutting the plastic.
3. Cut Cable ties holding the centre & side rollers – make sure you do not cut or damage the
fabric.
4. Remove the canvas cover bag by undoing the zip. The end parts of the cover bag which are
used to cover the vertical structure are folded back over the roof structure. These must be
carefully pulled outwards before loosening the zip.
5. At each end of the roof structure there are 3 threaded shafts. One end of the roof struc-
ture has a square shaft on the centre roller. This shaft fits into the vertical structure holding
the gearbox.
Your part of the deal is looking after them"
Pg:1 of 7
Advertisement
Related Manuals for Woodline Papillon
Summary of Contents for Woodline Papillon
- Page 1 2. Ensure that you are working in a clean area with ample space to assemble the Papillon. It is advisable to lay the roof structure onto a clean surface as the cover bag and roof canopy will get marks from a dirty surface.
- Page 2 15. Follow the same procedure as 11 through to 14 when assembling the other vertical pole and side arms to the roof structure. 16. Before lifting the Papillon – make sure that the selected base system is in the correct posi- tion (see base system positioning below).
-
Page 3: Product Handling
Moveable base and fixed mount products will have their own assembly instructions. PRODUCT HANDLING: 1. The Papillon is a shade system and is not designed to be a permanent shelter against rain. 2. The high-quality fabrics used, have the ability to repel water and will shelter you in wet and rainy conditions. - Page 4 o When opening make sure that the umbrella opens freely. The weight of the side rollers will cause the roof structure to open freely as the canvas is unwound. ▪ DO NOT FORCE the umbrella open if it seems to be jamming. This may result in damage to the crank holder or the gear mechanism.
- Page 5 o When both sides are down, proceed to roll up the roof structure by turning the crank handle until all the fabric is accumulated overhead. PARASOL SAFETY & STORAGE: o All umbrellas should be closed and secured when not in use. o Umbrella’s with free standing bases must never be left unattended as the product can and will move in strong winds.
- Page 6 o Once varnished - AVOID using a scourer or abrasive materials as this could affect the integ- rity of the surface finishes. o If in a marine / seaside environment, the maintenance procedures described above must be followed more frequently. Problems resulting from failure to maintain the products are not covered under warranty.
- Page 7 The above guarantees and warranties cover the replacement of fabric only and do not cover la- bour, installation, or freight. The sales invoice from the manufacturer or supplier must be retained to confirm the date of pur- chase. Pg:7 of 7...
