Pulley System
Stainless Steel
hook for coiling the
rope when umbrella
is open
www.woodlineshade.com Toll Free 1 – 800 – 260 – 0617
SWIFT UMBRELLA
ASSEMBLY INSTRUCTIONS
Stop Pin
Option of telescopic or
non-telescopic pole
*NOTE:
You may have purchased one of three bases for mounting the umbrella. The components comprising the base
mount system are in separate boxes from the umbrella. Locate your base mount system boxes, and assemble
the base system prior to removing the umbrella from the protective plastic bag.
For alternative base options please view www.woodlineshade.com
Concrete Slab Base
Round Metal Base
SWIFT 29/11/18
CONTENTS LIST
1 X UMBRELLA CANOPY (INCLUDING
COVER BAG) AND FRAME
1
1 X COVER BAG
2
1 X COVER BAG STICK
3
LOXX SPANNER
(IN ZIPLOC BAG ATTACHED
TO RUNNER ON THE
UMBRELLA STRUCTURE)
Square Metal Base
1/5
Advertisement
Related Manuals for Woodline SWIFT
Summary of Contents for Woodline SWIFT
- Page 1 SWIFT 29/11/18 CONTENTS LIST SWIFT UMBRELLA 1 X UMBRELLA CANOPY (INCLUDING COVER BAG) AND FRAME ASSEMBLY INSTRUCTIONS 1 X COVER BAG 1 X COVER BAG STICK Stop Pin Pulley System Stainless Steel hook for coiling the rope when umbrella LOXX SPANNER...
- Page 2 SWIFT 29/11/18 SWIFT CENTER POLE UMBRELLA CORRECT PLACEMENT model shape Round SW25RTS 8'0" 7'8" 6'9" 7'31" 3'6" 2.44 m 2.4 m 2.11 m 2.23 m 1.09 m Telescopic pole 6 arms Round SW25RSS 8'0" 5'4" 4'8" 7'31" 3'6" Non-telescopic pole 6 arms 2.4 m...
- Page 3 SWIFT 29/11/18 STEP 1 Glass filled nylon hub After assembling the base, remove the umbrella from the protective bags and set umbrella down on top of the bag to keep the canopy clean during the assembly. Loosen the fastening wheel(s) on the tube attached to the base, lift the umbrella and slide the pole into the tube. Turn the fastening wheel(s) clockwise until tight to secure the umbrella in the tube.
- Page 4 SWIFT 29/11/18 HOW TO FIT YOUR COVER BAG CORRECTLY CANOPY FOLDING INSTRUCTIONS In order to avoid the canopy fabric from being jammed between the frame components, it is important to pull the fabric out from the umbrella structure by putting a...
-
Page 5: Care And Maintenance
CARE AND MAINTENANCE Every Woodline shade solution is meticulously engineered to maximize not just their form and functions, but also to make sure that they outlast even the harshest conditions. Each item is crafted from the finest marine grade weather-resistant materials, specifically selected for their ability to endure.
