Woodline PACIFIC PC27RA Assembly Instructions Manual

Advertisement

Quick Links

PACIFIC UMBRELLA
ASSEMBLY INSTRUCTIONS
Concrete Slab Base
Paver Base
*NOTE: You may have purchased one of a variety of bases for mounting the umbrella.
The components comprising the base system are in separate boxes from the umbrella.
Locate your base mount system boxes, and assemble the base system prior to removing the
umbrella from the protective plastic bag.
For alternative base options please view www.woodlineshade.com
Square Metal Base
© WOODLINE PACIFIC 2023
BOX CONTENTS
PACKED
1 X FINIAL (ATTACHED
PACKED
TO TOP OF THE FRAME )
PACKED
PACKED
CANOPY BAG
1 X CANOPY
PACKED
LOXX SPANNER
IN ZIPLOC BAG
PACKED
PACKED BY:
DATE:
CHECKED BY:
DATE:
1/6
