8 PAVER BASE
DOUBLE STACK METAL BASE
woodlineshade.com Toll Free 1 – 800 – 260 – 0617
STORM UMBRELLA
ASSEMBLY INSTRUCTIONS
SUPPLIED IN SEPARATE BOX
*NOTE:
You may have purchased one of two bases for mounting the umbrella. The components
comprising the mount system are in separate boxes from the umbrella. Locate your
mount system boxes, and assemble the mount system prior to removing the umbrella
from the protective plastic bag.
Pulley
Fastening
Wheel
SUPPLIED PARTS
UMBRELLA
FRAME
CANVAS UMBRELLA CANOPY
PLASTIC PROTECTIVE DISC
(attached to top of umbrella frame)
(attached to top of umbrella frame)
L-shaped
Rope Coil Pin
8 x M6 X 16 COUNTERSUNK ALLEN SCREWS
Rope-Lock
Cleat
5mm ALLEN KEY
CANVAS COVER BAG
STORM 06/12/17
COVER
BAG STICK
FINIAL
1/5
Advertisement
Table of Contents
Related Manuals for Woodline STORM
Summary of Contents for Woodline STORM
- Page 1 STORM 06/12/17 SUPPLIED PARTS STORM UMBRELLA ASSEMBLY INSTRUCTIONS UMBRELLA COVER FRAME BAG STICK CANVAS UMBRELLA CANOPY SUPPLIED IN SEPARATE BOX *NOTE: PLASTIC PROTECTIVE DISC You may have purchased one of two bases for mounting the umbrella. The components (attached to top of umbrella frame) comprising the mount system are in separate boxes from the umbrella.
- Page 2 STORM 06/12/17 ASSEMBLY INSTRUCTIONS: STORM CENTER POLE UMBRELLA CORRECT PLACEMENT model shape A (size) A Canopy size: Round – size is measured from tip to tip through the center Round 11'5" 8'4" 7'5" 10'5" 2'7" ST35RSS Square – size is measured from tip to tip on one side 8 arms 3.5 m...
- Page 3 Remove the protective string and packaging from around the hub. H The Storm comes with a quattro pulley rope system for easy open and closing. Find the end of the rope hanging down from the Storm frame and guide it down through the pulley in the base stand, and attach the rope end plastic stopper to the very end of the rope and make a knot.
- Page 4 STORM 06/12/17 CANOPY FOLDING INSTRUCTIONS HOW TO FIT YOUR COVER BAG CORRECTLY In order to avoid the canopy fabric from being jammed between the frame components, it is important to pull the fabric out from the umbrella structure by putting a...
- Page 5 CARE AND MAINTENANCE Every Woodline shade solution is meticulously engineered to maximize not just their form and functions, but also to make sure that they outlast even the harshest conditions. Each item is crafted from the finest marine grade weather-resistant materials, specifically selected for their ability to endure.
