- Page 1 EASILIFT 24/08/21 EASILIFT UMBRELLA BOX CONTENTS ASSEMBLY INSTRUCTIONS PACKED 1 X FINIAL (IN SMALL BOX) PACKED PACKED PACKED CANOPY BAG 1 X CANOPY PACKED LOXX SPANNER PACKED PACKED PACKED BY: DATE: CHECKED BY: DATE: Concrete Slab Base Paver Base Square Metal Base...
- Page 2 EASILIFT 24/08/21 EASILIFT UMBRELLA - CORRECT PLACEMENT EA27RAS 8’10” 8’2” 7’1” 8’0” 3’1” 2.7m 2.49m 2.17m 2.46m 0.93m Canopy size: EA35RAS 11’5” Round – size is measured from tip to tip throu gh the center 3.5m Square – size is measured from tip to tip on one...
- Page 3 EASILIFT 24/08/21 FITTING THE CANOPY: After assembling the base and making sure the fastening handwheel is loosened, remove the umbrella structure from the protective bag, remove all protective wrapping and place the umbrella pole into the base tube, tightening the handwheel to ensure the umbrella is secured. To fit the canopy you will require a step ladder (although this process can also be done while laying the umbrella structure on its side on a clean flat surface, taking special care not to dirty the canopy).
- Page 4 EASILIFT 24/08/21 TO OPEN THE UMBRELLA Make sure the umbrella strap is loose. Gently pull outwards and upwards on a rib end to begin raising the structure - once you reach a certain point the self-lifting mechanism will take over, opening the umbrella with hardly any effort required on the part if the user.
- Page 5 EASILIFT 24/08/21 COVER STICK HOLDER POUCH FOR STORAGE OF COVER BAG STICK WHEN THE UMBRELLA IS CLOSED provide extra protection to prolong the lifespan and preserve the color of the canopy. Cover bag stick can be placed in the special pouch within the cover bag for...
- Page 6 EASILIFT 24/08/21 UV RESISTANT STAIN RESISTANT BLEACH SAFE STRONG & DURABLE MOLD RESISTANT EASY CARE...
