SMC Networks 55-MY1H-Z Series Instruction Manual

MY*H-SMV16EN
ORIGINAL INSTRUCTIONS
Refer to Declaration of
Conformity for relevant
Instruction Manual
Directives
Mechanically Jointed Rodless Cylinder
55-MY1H-Z Series
The intended use of this cylinder is to convert the energy for
compressed air into mechanical motion.
75°C (T6) Ta 5°C to 40°C
II 2G c
95°C (T5) Ta 40°C to 60°C
Marking description
Group II, Category 2
Suitable for Gas Environments
Type of protection "constructional safety"
o
The maximum surface temperature is 75 C and the temperature class is
T6 when the ambient temperature is:
o o
5 C to 40 C
o
The maximum surface temperature is 95 C and the temperature class is
o o
T5 when the ambient temperature is 40 C to 60 C
1 Safety Instructions
These safety instructions are intended to prevent hazardous situations
and/or equipment damage. These instructions indicate the level of
potential hazard with the labels of "Caution," "Warning" or "Danger."
They are all important notes for safety and must be followed in addition
*1)
to International Standards (ISO/IEC) , and other safety regulations.
*1)
ISO 4414: Pneumatic fluid power - - General rules relating to
systems.
ISO 4413: Hydraulic fluid power - - General rules relating to
systems.
IEC 60204-1: Safety of machinery - -Electrical equipment of
machines. (Part 1: General requirements)
ISO 10218-1: Manipulating industrial robots -Safety.etc.
This manual contains essential information for the protection of users
and others from possible injury and/or equipment damage.
 Read this manual before using the product, to ensure correct
handling, and read the manuals of related apparatus before use.
 Keep this manual in a safe place for future reference.
 To ensure safety of personnel and equipment the safety instructions
in this manual must be observed, along with other relevant safety
practices.
Caution indicates a hazard with a low level of risk
Caution
which, if not avoided, could result in minor or
moderate injury.
Warning indicates a hazard with a medium level
Warning
of risk which, if not avoided, could result in death
or serious injury.
Danger indicates a hazard with a high level of risk
Danger
which, if not avoided, will result in death or
serious injury.
Warning
 The compatibility of the product is the responsibility of the
person who designs the equipment or decides its specifications.
 Since the product specified here is used under various operating
conditions, its compatibility with specific equipment must be decided
by the person who designs the equipment or decides its
specifications based on necessary analysis and test results. The
expected performance and safety assurance of the equipment will be
the responsibility of the person who has determined its compatibility
with the product. This person should also continuously review all
specifications of the product referring to its latest catalogue
information, with a view to giving due consideration to any possibility
of equipment failure when configuring the equipment.
 Only personnel with appropriate training should operate
machinery and equipment.
The product specified here may become unsafe if handled
incorrectly.
The assembly, operation and maintenance of machines or equipment
including our products must be performed by an operator who is
appropriately trained and experienced.
 Do
not service or attempt to remove product
machinery/equipment until safety is confirmed.
1) The inspection and maintenance of machinery/equipment should
only be performed after measures to prevent falling or runaway of the
driven objects have been confirmed.
2) When the product is to be removed, confirm that the safety
measures as mentioned above are implemented and the power from
any appropriate source is cut, and read and understand the specific
product precautions of all relevant products carefully.
3) Before machinery/equipment is restarted, take measures to
prevent unexpected operation and malfunction.
 Contact SMC beforehand and take special consideration of
safety measures if the product is to be used in any of the
following conditions.
1) Conditions and environments outside of the given specifications, or
use outdoors or in a place exposed to direct sunlight.
2) Installation on equipment in conjunction with atomic energy,
railways, air navigation, space, shipping, vehicles, military, medical
treatment, combustions and recreation, or equipment in contact with
food and beverages, emergency stop circuits, clutch and brake
circuits in press applications, safety equipment or other applications
unsuitable for the standard specification described in the product
catalogue.
3) An application which could have negative effects on people,
property, or animals requiring special safety analysis.
4) Use in an interlock circuit, which requires the provision of double
interlock for possible failure by using a mechanical protective
function, and periodical checks to confirm proper operation.
 Always ensure compliance with relevant safety laws and
standards.
All electrical work must be carried out in a safe manner by a qualified
person in compliance with applicable national regulations.
Caution
 The product is provided for use in manufacturing industries.
The product herein described is basically provided for peaceful use in
manufacturing industries.
If considering using the product in other industries, consult SMC
beforehand and exchange specifications or a contract if necessary.
If anything is unclear, contact your nearest sales branch.
2 Specifications
2.1 Specification
Refer to the operation manual for this product.
Fluid Air
Max. operating pressure 0.8 MPa
Min. operating pressure 0.1 MPa
Ambient and fluid temperature 5 to 60°C
Lubrication
Not required
Cushioning Air Cushion
Operating piston speed
Allowable Ø25
Kinetic Ø32
Energy
Ø40
Explosive atmosphere
Zone
2.2 Production Batch Codes
Production batch codes
...
Year 2016 2017 2018 2021
...
Month U V W Z
...
Jan O UO VO WO ZO
...
Feb P UP VP WP ZP
...
Mar Q UQ VQ WQ ZQ
...
Apr R UR VR WR ZR
...
May S US VS WS ZS
...
Jun T UT VT WT ZT
...
Jul U UU VU WU ZU
...
Aug V UV VV WV ZV
...
Sep W UW VW WW ZW
and
...
Oct X UX VX WX ZX
...
Nov Y UY VY WY ZY
...
Dec Z UZ VZ WZ ZZ
3 Installation
3.1 Installation
Warning
Do not install the product unless the safety instructions have been read
and understood.

Do not apply strong impacts or excessive moments to the slide
table (slider).
The slide table (slider) is supported by precision bearings. Therefore, do
not apply strong impacts or excessive moment, etc., when mounting
work pieces.
 Align carefully when connecting to a load having an external guide
mechanism.
Mechanically jointed rodless cylinders can be used with a direct load
within the allowable range for each type of guide, but careful alignment
is necessary when connecting to a load having an external guide
mechanism. As the stroke becomes longer, variations in the centre axis
become larger. Consider using a flexible connection method (floating
mechanism) that is able to absorb these variations. Furthermore, use
the special floating brackets which have been designed for series
MY1B.
 Do not scratch or gouge the cylinder tube by striking or grasping it
with other objects.
Cylinder bores are manufactured to precise tolerances therefore even a
slight deformation may cause malfunction.
 Do not use until you can verify that equipment can operate
properly.
Verify correct mounting by suitable function and leakage inspections
after compressed air and power are connected following mounting,
maintenance or conversions.
 Instruction Manual.
The product should be mounted and operated after thoroughly reading
the manual and understanding its contents. Keep the instruction manual
where it can be referred to as needed.
 Ensure that the air supply system is filtered to 5 microns.
 Provide intermediate supports for long stroke cylinders.
Provide intermediate supports for cylinders with long strokes to prevent
bending of the tube, and deflection due to vibration and external loads.
100 ~ 1000 mm/s
1.7 J
 Intermediate stops.
3.4 J
Due to the compressibility of air, it is difficult for this product to make a
6.2 J
piston stop at the required intermediate position accurately and
Gas
precisely.
1 and 2
Mechanical joint rodless cylinder has a special seal in the construction,
and this causes a small amount of external air leakage. A three position
closed centre type directional control valve may not hold the slide table
in the intermediate position for an extended period of time, and the
speed may not be controlled when restarting the operation.
...
2022 2023
Use of the actuator in this manner is not recommended. If Intermediate
...
A B
stops are required use three position pressure centre type directional
...
AO BO
control valve and a holding mechanism if stop are required for
...
AP BP
prolonged periods of time.
...
AQ BQ
...
AR BR
...
AS BS
3.2 Environment
...
AT BT
...
AU BU
 Do not use in an environment where corrosive gases, chemicals, salt
...
AV BV
water or steam are present.
...
AW BW
 Do not use in an explosive atmosphere except within the specified
...
AX BX
rating.
...
AY BY
 Do not expose to direct sunlight. Use a suitable protective cover.
...
AZ BZ
 Do not install in a location subject to vibration or impact. Check the
product specifications.
 Do not mount in a location exposed to radiant heat.
 Do not use in case of heavy dusty environments where dust can
penetrate into the cylinder and dry the grease.
 Do not use in a wet environment.
3.3 Piping
 Before piping make sure to clean up chips, cutting oil, dust etc.
 When installing piping or fittings, ensure sealant material does not
enter inside the port. When using seal tape, leave 1 thread exposed
on the end of the pipe/fitting.
 Tighten fittings to the specified tightening torque.
Bore size (mm)
Ø25 & Ø32
Ø40
3.4 Lubrication
 SMC products have been lubricated for life at manufacture, and do
not require lubrication in service.
 If a lubricant is used in the system, use turbine oil Class 1 (no
additive), ISO VG32. Once lubricant is used in the system, lubrication
must be continued because the original lubricant applied during
manufacturing will be washed away.
3.5 Electrical Connection
 Provide a grounding connection to the actuator to avoid any spark
arising from potential differences.
Warning
Warning
Caution
Port size
1/8
¼
Caution
Warning
