2162i-2_Manuals 8/22/17 9:14 AM Page 1
130 Laser Distance Meter w/Bluetooth
®
Model No. LDM130
Instruction Manual
Congratulations on your choice of this Laser Distance Meter. We suggest
you read this instruction manual thoroughly before using the instrument
and save this instruction manual for future use.
This is a Class II laser tool and is manufactured to comply with CRF 21,
parts 1040.10 and 1040.11 as well as international safety rule IEC 285.
The laser also complies with EMC Test according to EN61000-6-3;
2001+A11:2004, EN 6100-6-1:2011, EN 6100-4-2, EN 61000-4-3, EN
60825, FCC Test according to PART 15.
©2017 Johnson Level & Tool
1
Advertisement
Table of Contents
Related Manuals for Johnson LDM130
Summary of Contents for Johnson LDM130
- Page 1 1040.10 and 1040.11 as well as international safety rule IEC 285. The laser also complies with EMC Test according to EN61000-6-3; 2001+A11:2004, EN 6100-6-1:2011, EN 6100-4-2, EN 61000-4-3, EN 60825, FCC Test according to PART 15. ©2017 Johnson Level & Tool...
-
Page 2: Table Of Contents
5. Location of Parts/Components 13. Product Warranty 6. Battery Installation 14. Warranty Registration 7. Operating Instructions 15. Accessories 1. Kit Contents Description Qty. Laser Distance Meter “AAA” Alkaline Batteries Wrist Strap Soft-Sided Pouch Quick Start Guide ©2017 Johnson Level & Tool... -
Page 3: Features And Functions
• ISO 16331-1 tested* to typical accuracy of +/- 1/16″ (0.0625″, or 1.5mm) • Bluetooth ® enabled for syncing with the Johnson Measure-Up (iOS or Android) • High-speed microprocessor for quick, accurate calculations • IP 54 protection – sealed from dust and rainwater * This tool is tested in accordance with ISO 16331-1 “Laboratory... -
Page 4: Safety Instructions
• Do not attempt to repair or disassemble the laser tool. If unqualified persons attempt to repair this tool, warranty will be void. • Use only original Johnson ® parts and accessories purchased from your Johnson ® ® authorized dealer. Use of non-Johnson parts and accessories will void warranty. -
Page 5: Location/Content
6. Ambient Light – The tool is being used in too bright of an environment to operate properly. QR Code: Use a smartphone to scan the QR code to be taken directly to Johnson Level & Tool’s Operator’s Manual Page. ©2017 Johnson Level & Tool... -
Page 6: Location Of Parts/Components
• Area measurement urement reference • Volume measurement Press and hold for: • Indirect/2-Point • Enable / disable Pythagoras measurement Bluetooth ® Press and hold for: • Sound (High, Low, Off) Laser Receiving Window Laser Emitted Window ©2017 Johnson Level & Tool... - Page 7 2162i-2_Manuals 8/22/17 9:15 AM Page 7 LCD Screen Not all features found on the LCD screen are found in every Johnson Level & Tool Laser Distance Meter. See the notes below for further information. 1. Measurement Reference Position 8. Minimum Display 2.
-
Page 8: Battery Installation
Notes: • Use only alkaline batteries. • Remove the batteries when storing the instrument for an extended time (more than 3 months) to avoid damage to the tool should the batteries deteriorate. ©2017 Johnson Level & Tool... -
Page 9: Operating Instructions
Automatic Shutoff Laser will turn off after remaining idle for 2 minutes. Press the button to re-enable the laser. Unit will turn off after remaining idle for 5 minutes. ©2017 Johnson Level & Tool... - Page 10 Measuring Modes The Laser Distance Meter has 4 measuring modes. When the instrument is powered on, it will default to the Length measuring mode. 1. Length (Single or Continuous) 2. Area/Square 3. Volume/Cube 4. 2-Point Pythagoras ©2017 Johnson Level & Tool...
- Page 11 OR after taking a measurement, press the button to scroll through the various units of measurement. Note: The screen will only display feet and meters in a decimal format in Area or Volume modes. ©2017 Johnson Level & Tool...
- Page 12 To select the desired position, press the button. The laser indicator icon at the top left of the LCD screen will display the selected position. Front of Unit Zero Back of Unit Zero Reference Position Reference Position ©2017 Johnson Level & Tool...
- Page 13 4. Press the button or button to pause the measurement. The laser will turn off. 5. To exit the continuous mode and return to the single length measurement mode, press the button while the tool is paused. ©2017 Johnson Level & Tool...
- Page 14 The laser will turn off. 6. Press the button again to take your next Area measurement. ©2017 Johnson Level & Tool...
- Page 15 The laser will turn off. 8. Press the button again to take your next Volume measurement. ©2017 Johnson Level & Tool...
- Page 16 (represented by “C” in the figure above) and indicated by the flashing lines on the LCD screen). 3. Keep your position stable and press the button. The hypotenuse length measurement will appear above the main display. ©2017 Johnson Level & Tool...
- Page 17 3. Complete your second measurement. The second measurement will appear above the main display, and the sum of the two measurements will appear in the main display. 4. Repeat step 3 above as necessary to add further measurements. ©2017 Johnson Level & Tool...
-
Page 18: Using The Bluetooth
Power up the LDM and press and hold the Bluetooth ® button until the Bluetooth ® indicator on the LDM screen flashes. Keep the LDM in length mode the entire time you use it with the app. ©2017 Johnson Level & Tool... - Page 19 To append a voice, text, or video message to the picture, click the Video Check mark Dimension Audio LDM Bluetooth/ Refresh button and select video , audio or text Record Text Record Text Video Check mark Record Text ©2017 Johnson Level & Tool...
- Page 20 . You can return to your image in the app Record Text later, or you can export it by pressing . It can be emailed, or sent via many popular messaging or storage apps. ©2017 Johnson Level & Tool...
-
Page 21: Tips From The Pros
• When making Pythagoras measurements, make sure that you hold the tool as flat as possible during your second measurement for the most accurate measurements. The beam should hit perpendicular to the object you are measuring. ©2017 Johnson Level & Tool... -
Page 22: Care And Handling
•Keep the laser unit dry and clean, especially the laser output window. Remove any moisture or dirt with a soft, dry cloth. •Do not use harsh chemicals, strong detergents or cleaning solvents to clean the unit. ©2017 Johnson Level & Tool... -
Page 23: Troubleshooting Guide
Check battery polarity Turns off after a short Batteries depleted Change the batteries time Measurement seems Incorrect reference Set the reference incorrect position used position to the front rear edge of the tool, as appropriate ©2017 Johnson Level & Tool... -
Page 24: Technical Specifications
2 “AAA” alkaline batteries (included) Battery Life Minimum 10 hours/10,000 measurements Operating Temperature Range 23°F - 104°F Storage Temperature Range -4°F - 160°F Dimensions 4.1″x1.9″x0.8″ Weight 3 oz. including batteries; 2.25 oz. excluding batteries IP Rating IP 54 ©2017 Johnson Level & Tool... -
Page 25: Product Warranty
Overcast or darker days will offer a longer working range. 13. Product Warranty Johnson Level & Tool offers a two year limited warranty on each of its products. You can obtain a copy of the limited warranty for a Johnson Level & Tool product by contacting Johnson Level &... -
Page 26: Warranty Registration
NO WARRANTY. If you need any assistance in locating any accessories, please contact our Customer Service Department. In the U.S., contact Johnson Level & Tool’s Customer Service Department at 888-9-LEVELS. In Canada, contact Johnson Level & Tool’s Customer Service Department at 800-346-6682.
