SYSTEM 2316 Installation Manual
The following is a summary of the questions most frequently asked of our Technical Support Department.
Question:
How do I program the panel with the LED keypad?
Answer:
To program with the LED keypad, enter the Command Location to be programmed, the Data to be pro-
grammed and the press the [#] key. (See also pages 6 - 7.)
For Example:
How do I access Alpha Keypad Programming to enter Zone Labels?
Question:
Answer:
To begin Alpha Keypad Programming (you cannot program the LED keypad), enter [Installer Combination]
[*] [0] [1] [#]. Then scroll to the desired message location. (See also pages 7 - 8.)
Question:
How do I interpret a Trouble on the LED keypad? How do I clear a Trouble on the LED keypad?
Answer:
A number of conditions may cause the Trouble LED to light. See the chart below for additional information.
Question:
How do I enter hexadecimal numbers when using keypad programming?
Answer:
Hexadecimal values are entered through the use of the [*] key and one of the digits [0] - [5]. For additional
help with entering hexadecimal numbers, refer to page 7. The hexadecimal conversion chart is also found
at various locations throughout the programming section of the manual.
Question:
What is an "Interface error 1" and how do I correct the error?
Answer:
This error is caused by a problem with the Data line (Green wire) between the panel and the keypad.
Check the connection to ensure that the wire is not pinched or loose. Also try disconnecting all keypads
from the panel (one at a time), resetting the panel after each keypad is removed. Remember, to reset the
panel press: [Master Code] [*] [6] [8] [#].
Question:
How do I reset Alarm Memory?
Answer:
To Clear Alarm Memory, press [*] [1] [#].
Question:
How do I address an Alpha Keypad for the first time?
Answer:
If you have an Alpha keypad that has never been addressed, when power is initially applied, the display
will read KEYPAD ADDRESS?. To enter the address, simply press a number between 0 and 7. Remove
panel power for 3 seconds and then re-apply power to reset the system. For additional information about
Keypad addressing, see page 5.
NOTE:
How do I interpret the Unit Status Reports? Can the codes be changed?
Question:
Answer:
The Reporting Codes for the Unit Status Report is a two-digit code. The first digit is programmed into CL
2A Digit Position (3) and may be any value from 0 - F. The second digit is fixed by the firmware and cannot
be changed. Please note that programming a 0 into 2A (3) will disable the report and no Unit Status
information will be sent. Additional information about Unit Status Reporting Codes can be found on page
17 in the programming section.
Survey of Most Common Questions
To program User #2 with the ability to Arm only, No Reports and No Shunting; and
a PIN of 6543, enter the following keystrokes:
CL
Arm Type
[0][2]
[1]
Trouble LED
Power LED
Flash Slow
On
On
On
On
Off
On
Flash Slow
On
On
If operating at or near the limit of AUX Power and Keypad Power, you may need to remove
power for up to 30 seconds in order for the system to reset properly.
PIN (w/EON)
Write Data
[6][5][4][3][*][4]
[#]
Zone LED's
Cause
Off
Watchdog
Flash Slow
Zone Trouble
Off
AC Failure
Off
Low Battery
Off
System Trouble (Bell Fuse or
22
Comm Fail.)
