CL A0, B3 and B4
Command Location A0: Test Report Countdown Timer
This command will set the time when the first Test Report is transmitted to the central
station. The panel will use this transmission time each time it's powered up or the CPU
is reset (unless Command Location A0 is reprogrammed).
Previously stored data is not displayed during programming.
Digit Position (1): Set Test Report Countdown Timer
0 = 1/4 hour
4 = 3 hours
1 = 1/2 hour
5 = 4 hours
2 = 1 hour
6 = 6 hours
3 = 2 hours 7 = 8 hours
Command Location B3: Set Real-Time Clock (Year, Month, Day)
This command will set the day, month, and year in
the panel, and will not take effect until Command B4
is programmed.
Previously stored data is not displayed during programming.
Digit Position (1): Year - 10's
Digit Position (2): Year - 1's
Digit Position (3): Month - 10's
Digit Position (4): Month - 1's
Digit Position (5): Day - 10's
Digit Position (6): Day - 1's
Command Location B4: Set Real-Time Clock (Hour, Minute, Second)
This command will set the hour, minute, and second
in the panel. The time is set in BCD (military time).
Previously stored data is not displayed during programming.
Digit Position (1): Hour - 10's
Digit Position (2): Hour - 1's
Digit Position (3): Minutes - 10's
Digit Position (4): Minutes - 1's
Digit Position (5): Seconds - 10's
Digit Position (6): Seconds - 1's
8 = 10 hours 2 = 18 hours
9 = 12 hours 3 = 20 hours
0 = 14 hours 4 = 22 hours
1 = 16 hours 5 = 24 hours
Example: If the date were April 12, 1993, B3 would be programmed
Example: If the time were 28 and one-half minutes past 1 in the afternoon, B4 would be programmed
NOTE: Refer to CL 2B for setting the time
interval between Reports.
Example: The time is 1500 hours (3:00 pm). You want the first Test Report
to transmit at 0100 hours (1:00 am). 3:00 pm + 10 hours = 1:00
am. Program the value "8" in Memory Location A0.
B 3
(1) (2)
YEAR MONTH
9 3 0 4 1 2
B 3
(1) (2) (3) (4)
B 4
(1)
(2)
HOUR MINUTE SECOND
1 3 2 8 3 0
B 4
(1) (2) (3)
