C&K systems SYSTEM 2316 Installation Manual page 15

CL 2A and 2B
Command Location 2A: Event Reporting
Digit Position (1): Shunt Receiver Select
See also CL 17 - 1E & 40 - 47 Digit Positions (5) and (6).
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
Digit Position (2): Restore Receiver Select
See also CL 17 - 1E & 40 - 47 Digit Positions (3) and (4).
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
Digit Position (3): Unit Status Report Code
Valid entries are 0 - F.
The panel will add a fixed extension digit when reporting. Fixed codes are listed below.
Program a 0 at this position to disable Unit Status Reporting.
Digit Position (4): Unit Status Receiver Select
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
Digit Position (5): Cancel Report Code
Valid entries are 0 - F.
The panel will add the User ID # as the second digit when reporting.
Program a 0 at this position to disable Cancel Reports.
Digit Position (6): Cancel Report Receiver Select
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
UNIT STATUS FIXED EXTENSION CODES
1 = Low battery
2 = AC fail
3 = Bell fuse fail
5 = Failed to communicate
6 = Battery restore
Command Location 2B: Test Report
Digit Positions (1) and (2): Test Report Code
Valid entries are 0 - F.
Program 00 to disable Test Reports.
Digit Positions (3): Test Report Receiver Select
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
Digit Positions (4): Test Report Interval
1 = 1 hour 5 = 24 hours
2 = 2 hours 6 = 7 days
3 = 4 hours 7 = 14 days
4 = 12 hours 8 = 21 days
9 = 30 days
Default Values
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
7 = AC restore
8 = Bell fuse restore
B = Watchdog reset
C = Completed programming
Default Values
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
0 = 1 hour if armed
1 = 2 hours if armed
2 = 4 hours if armed
3 = 12 hours if armed
4 = 24 hours if armed
1 1
2 A
(1) (2)
2 B
NOTE: CL A0 must be programmed to
correctly set time of test.
15
SYSTEM 2316 Installation Manual
A 1 D 1
(3) (4) (5) (6)
0 0 1 6
(1) (2) (3) (4)
#
#
