Command Locations 30 - 3F: Loop Switches
30 = Loop 1 34 = Loop 5
31 = Loop 2 35 = Loop 6
32 = Loop 3 36 = Loop 7
33 = Loop 4 37 = Loop 8
Digit Position (1): Enable Door Chime
0 = No
1 = Yes: keypads beep 2 seconds when faulted (disarmed condition)
Digit Position (2): Allow Shunting of This Loop
0 = No: makes it a priority zone (not shuntable)
1 = Yes: authorized users can bypass or force arm
Digit Position (3): Allow Group Shunting for This Loop
0 = No
1 = Yes: include as part of group when performing Home Arming or Instant/Home Arming feature
(See CL 09 Digit Position (5) and pages 21 & 25 )
Digit Position (4): Delay Before Dial
0 = No
1 = Yes: this loop will delay dialing on alarm for time programmed in 0B (1)
Command Location 48: Trouble Reports
Digit Position (1): Trouble Report Code
This is a one-digit reporting code.
Program 0 to disable Trouble Report.
Digit Position (2): Trouble Report Receiver Select
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
Digit Position (3): Trouble Restoral Report Code
This is a one-digit reporting code.
Program 0 to disable Trouble Restoral Report.
Digit Position (4): Trouble Restoral Report Receiver Select
0 = Receiver 1 with Receiver 2 as back-up
1 = Receiver 1 only
Default Values
38 = Loop 9 3C = Loop 13
39 = Loop 10 3D = Loop 14
3A = Loop 11 3E = Loop 15
3B = Loop 12 3F = Loop 16
Default Values
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
2 = Receiver 2 only
3 = Receiver 1 and Receiver 2 (Dual Reporting)
NOTE: Some keypads may have a
an [ENTER] key in place of the [*] and [#] keys,
respectively. This manual uses the [*] for the [SHIFT]
key and the [#] for the [ENTER] key.
3 0
Refer to CL 01 - 08 & 51 - 58 Digit Position (1) for
Arming Types (Authorization Levels)
4 8
[SHIFT] key and
18
CL 30 - 3F & 48
0 1 0 0
(1) (2) (3) (4)
F 1 E 1
(1) (2) (3) (4)
PROGRAMMING CONVERSIONS
Hexadecimal Value
A
B
C
D
E
F
#
#
Key Strokes
0
1
2
3
4
5
