Web-Based Management - D-Link DVG-1120S Manual

Web-based Management

In order to use a web browser to configure the VoIP gateway, you must make
sure it has a valid Ethernet connection to a PC or LAN via its LAN port.
Access the configuration utility to check the LAN port by entering the IP Address
into your web browser address field.
Type 192.168.15.1
(the IP Address) into
the address field of
your browser.
Click on Login to the
Web-based
Management
module.
Initially, the VoIP
gateway does not have
a Username or
Password. To log in,
simply click on the OK
button.
After logging in, the
Device Info screen on
the following page will
be displayed.
http://192.168.15.1
192.168.15.1
