Hardware Installation

Connect to a Network
If you are connecting the DCS-2100G to a wired Ethernet network, connect an Ethernet
cable to the network cable connector located on the Internet Camera's bottom panel
and attach it to the network.
If you are connecting the DCS-2100G to a 802.11g wireless Ethernet network, attach
the one wireless antenna to the antenna connector on the side panel of the
DCS-2100G.
Attach the external power supply
Attach the external power supply to the DC power input connector located on the Internet
Camera's bottom panel (labeled 5VDC) and connect it to your wall outlet. When you
have a proper connection, the LED will light up.
