- Page 1 OPERATION AND MAINTENANCE MANUAL Portable Pediatric Dental Chair ADC-01P (gray) ADC-01P-RED (red) ADC-01P-BLU (blue)
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction ..............3 Purpose . -
Page 3: Introduction
INTRODUCTION: SAFETY PRECAUTIONS: Aseptico’s Portable Pediatric Dental Chair is intended Aseptico accepts no liability for direct or consequential injury to provide adolescent patient seating for field dentistry or damage resulting from improper use, arising in particular and medical treatment. The chair is fully adjustable... -
Page 4: Operation Instructions
CHAIR SET-UP: 1. Remove the chair from its carrying Adjustment case and set it on the floor, legs Pins down, in its folded position. 2. Rotate the chair up onto one side and remove the leg adjustment pins from their storage pouch underneath the chair seat. -
Page 5: Chair Adjustments
CHAIR ADJUSTMENTS: 1. Seat Height- The chair seat height can be set at any of the five preset settings. Without a patient in the chair, put your toe on one of the front chair legs and lift up slightly on the chair seat. While lifting and holding seat, remove the leg adjustment pin Lift lever to position. -
Page 6: Collapsing The Chair
COLLAPSING THE CHAIR: WARNING NEVER FORCE THE CHAIR INTO THE COLLAPSED POSITION. FORCING THE CHAIR DOWN WITHOUT RELEASING THE BACKREST ADJUSTMENT LEVER MAY BEND THE ADJUST- MENT ASSEMBLY AND WILL VOID THE WARRANTY. 1. Fold toe and then leg sections onto seat as it was originally stored. 2. - Page 7 NOTES Page 7...
-
Page 8: Parts List
PARTS LIST Item ADC-01P ADC-01P-RED ADC-01P-BLU Quantity Seat Cover Assembly 460451 460451-01 462551 Armrest Right 460447 460447-01 462550 Armrest Left 460447 460447-01 462550 Cover, backrest 462710 461845 462711 Strap, headrest 460449 461847 462538 <— <— Screw, #8x5/8" Chrome SEMS 510239... -
Page 9: Parts Diagram
Figure 7 - Parts Diagram... -
Page 10: Symbol Definitions
SYMBOL DEFINITIONS: Part Number Serial Number UDI: Unique Device Identifier MD - Medical Device Authorized European Representative Dental Use Only Authorized United Kingdom Representative... - Page 11 NOTES...
-
Page 12: Warranty
During the specific warranty periods set forth above, Aseptico will, at its option, repair or replace the product(s) or particular part(s) that are found to be defective in either material or workmanship in part or whole. Aseptico shall be the sole arbiter of such action.
