ADC-02CF • Setup Guide
Portable Hydraulic Dental Chair • NSN: 6520-01-652-8993
Leg Panel
Foot Panel
Stabilizer
1.
Using two people, lift the chair
the transport case and set it on the
floor.
A
Arm Sling
Arm Post
Backrest Cylinder
Backrest Strap
A
from
2.
Pull out the stabilizer
as a handle to tilt the chair up on its
B
wheels
it will be used.
A
Pillow
A
and use it
, then roll the chair to where
B
Backrest Frame
Backrest Latch
Leveling Foot
Wheel
Selector Lever
3.
Set the chair back down on the floor
making sure the stabilizer
extended. Remove the backrest
strap
B
from the chair.
A
CONTINUED ON BACK . . .
Lift Lever
A
is fully
B
