Mounting instructions DMZ271
Free-standing base plate 800 x 800 x 12 mm for FILIUS.
The following instructions include all information necessary for the assembly and
operation of this
base plate.
instructions carefully and then
Non- observation of mounting instructions can result in personal
injuries or damage to property.
Please note that if these instructions are not observed, the manufacturer cannot
Caution
assume any liability or guarantee.
Always follow the safety regulations.
Should you not understand any part of these mounting instructions, please
contact your MAY dealer.
Diagram showing mounting materials
Stand 36-1216
To avoid any misunderstanding we advise you to read these
keep them for later reference.
English
base clamp for parasol fixation
bore hole for theft and
anti-twisting lock
steel plate 800 x 800 x 12 mm
page 1 of 7
Advertisement
Related Manuals for MAY DMZ271
Summary of Contents for MAY DMZ271
- Page 1 Mounting instructions DMZ271 Free-standing base plate 800 x 800 x 12 mm for FILIUS. The following instructions include all information necessary for the assembly and operation of this To avoid any misunderstanding we advise you to read these base plate.
- Page 2 The weight of the steel plates prevent the parasol from vertical lifting. However, if the wind is coming from the side the parasol base plate may slip on the terrace surface. Base plates that are not secured against strong crosswinds may cause personal injuries and damage to property.
- Page 3 1. Allow sufficient space between sunshades or between the wall of the house and the sunshade. Sunshades that are located too close together wear sooner. Sunshades may sway slightly. If there is not enough space between them, they may touch and abrade or scour the canopy fabric at the spoke ends. Caution ...
- Page 4 A falling sunshade cause serious or even fatal injury. If, when the sunshade is open, the wind speed exceeds Beaufort 5 (horizontal Danger wind), the whole construction may topple and cause damage to property or personal injury. Immediately close the sunshade whenever wind rises.
- Page 5 780 x 780 x 12 mm, for MEZZO, DACAPO und FILIUS Fits for free-standing base plate DMZ271 and DMZ139, for retrofitting. DMZ271 or DMZ139 combined with the add-on weight (art. no. 351185) reach the suitable weight to be used with MEZZO or DACAPO.
- Page 6 2. Turn the add-on weight plate so the countersinks and chamfers facing up. 3. Put the add-on weight plate onto the base plate centrically. Make sure the edges of the two plates are aligned parallel. Stand 36-1216 English page 6 of 7...
- Page 7 4. Choose two opposite lying corners and screw in the 2 supplied countersunk screws completely (use a 5 mm hex key). 5. Attach the base clamp and use a 6 mm hex key to tighten the screw. Stand 36-1216 English page 7 of 7...
