Installation instructions type ALBATROS
Suitable for installation options with placement hinge
AZ024
Thank you very much for purchasing a MAY parasol.
The following instructions include all information necessary for the correct assembly, operation and
maintenance of your MAY parasol. To guarantee absolute safety when handling your parasol,
please read these instructions carefully and then keep them for later reference.
Stand 38-1408
AZ120
AZ128
Deutsch / English / Français
AZ186
AZ194
AZ210
AZ246
AZ247
AZ248
AZ249
page 1 of 22
AZ256
AZ257
AZ258
Advertisement
Table of Contents
Related Manuals for MAY ALBATROS AZ024
Summary of Contents for MAY ALBATROS AZ024
- Page 1 Thank you very much for purchasing a MAY parasol. The following instructions include all information necessary for the correct assembly, operation and maintenance of your MAY parasol. To guarantee absolute safety when handling your parasol, please read these instructions carefully and then keep them for later reference.
-
Page 2: Table Of Contents
Content page 03 Assembly: Preparing the anchor tube page 05 Assembly: Unpacking the parasol page 08 Assembly: Erecting the parasol page 10 Operation: Opening the parasol page 12 Assembly: Aligning the parasol page 13 Assembly: Theft and anti-twisting lock page 14 General information page 15 Operation: Closing the parasol... - Page 3 • Always follow the safety regulations. • Should you not understand any part of these operating instructions, please contact your MAY dealer. Wind can damage your parasol. No guarantee possible. • Always completely open or close the parasol. Never leave it merely half-opened, as it is then not fully stable.
- Page 4 2. Loosen the M16 screws of the anchor foot plate. M16 socket head screw, 4x 3. Tilt the upper anchor foot until it is in a horizontal position. 4. Loosen the four M10 socket head screws of the upper anchor foot until there is sufficient clearance inside the anchor foot for the centre pole to be inserted horizontally.
-
Page 5: Assembly: Unpacking The Parasol
T30 bit to remove the torx screws. Pulling out the parasol from the cardboard sleeve may damage the canopy. The torx screws that hold the end cap of the carboard sleeve may cut the canopy while it’s been pulled out. - Page 6 Especially when all hands hold onto one side and grips are changed on waist Caution height, the parasol may roll off the arms or become unbalanced so everyone falls with the parasol. • Avoid all risks of tripping on the route of transport. Clean the ground where the parasol is to be positioned.
- Page 7 8. Put the parasol into the MAY setup aid (if purchased, art. no. 352040) or onto a chair. Laying down the parasol may damage the canopy.
-
Page 8: Assembly: Erecting The Parasol
M10 socket head screw, 4x Assembly: Erecting the parasol 1. Remove the foam package. If a knife is used to remove the packaging, the protective sleeve and the canopy fabric may get damaged. Caution • Do not use a knife or any other sharp instrument to remove the packaging. - Page 9 30mA). Please note: according to legal requirements, RCB/RCBO protection switches must be checked Danger by the operator at least every six months. Non observation may result in personal injuries. electric connection 5. Errect the parasol. Deutsch / English / Français...
-
Page 10: Operation: Opening The Parasol
A falling parasol can cause serious or even fatal injury. If too few people attempt to erect the parasol, it may become too heavy and uncontrollable, thus causing a serious accident. Danger • It takes at least four adults to erect the parasol. - Page 11 A falling parasol can cause serious or even fatal injury. If the parasol is not firmly anchored in the anchor foot, it may be lifted by the wind. Danger • Make sure all screws of the anchor foot are tightened firmly.
-
Page 12: Assembly: Aligning The Parasol
A parasol may be a danger zone. Make sure that there are no other people or items standing around while the parasol is being Caution erected. If the parasol is not fully opened, it wears out more quickly. Only if the parasol is fully opened, the canopy is fully stretched and reaches its maximum stability. -
Page 13: Assembly: Theft And Anti-Twisting Lock
• Secure the M10 socket head screws with the locknuts. Assembly: Theft and anti-twisting lock Drilling holes for theft and anti-twisting lock may ruin the electric motor (if installed). • If the parasol is equipped with an electric motor, do not drill holes to mount the theft and Warning anti-twisting lock. -
Page 14: General Information
Only for parasols operated with electric power: Drilling may damage electric cables that are routed through the pole of the parasol. • Make sure the cable is not energized. Caution • Be sure to avoid routing the cables inside the parasol pole too close to bore holes, otherwise they will be penetrated or damaged by the drill. -
Page 15: Operation: Closing The Parasol
Extreme environmental impacts may cause personal injury and material damage. If a parasol is exposed to excessive strain it may get damaged or even ruined. The spokes, the canopy or the centre pole may get damaged. Also, surrounding objects may be affected. - Page 16 3. Secure the parasol with the strap provided, use a freestanding ladder, if available. Wind can do damage to an unsecured parasol and may lead to abrasion of the canopy fabric. No guarantee possible! Caution • In case of a round parasol 1 strap is sufficient, positioned above the spoke end.
- Page 17 4. Pull the protective sleeve provided over the parasol. Wind can do damage to an unsecured parasol and may lead to abrasion of the canopy fabric. No guarantee possible! Even if the parasol is closed and secured by strap there are still parts of the canopy that cannot Caution be secured by the strap and may therefore move in the wind.
-
Page 18: Assembly: Storing The Parasol
3. Put the cap back onto the rectangular tube. Storing the parasol If possible, leave the parasol outside throughout the whole year. Unprofessional storage may rather lead to damages than leaving the parasol outside. There are several reasons for winter storage, e.g. if there is no vandalism protection given or if the city administration requires parasol removal. - Page 19 3. Store the parasol away from mice. Mice like to gnaw on textiles. This causes material damage. If the parasol is not protected from mice, they may damage the canopy. Please always check Caution each storage to make sure mice will not get in.
-
Page 20: Maintenance And Cleaning
• Follow our cleaning instructions for cleaning your parasol. Caution 3. The MAY company will be pleased to overhaul your parasol and clean the canopy fabric for you. However, this is only possible off-season, i.e. from October to December. 4. Please contact your local retailer to clarify the transport to the May company. -
Page 21: Assembly: Tools And Aids
This chapter helps the technician to get optimally prepared. Use the following checklist to guarantee a smooth and professional assembly. All items required are listed below. Depending on individual circumstances it may be helpful to have your regular tools and aids available as well. -
Page 22: Delivery And Acceptance Certificate
The customer has been instructed properly according to the operating manual of the parasol. The customer received following documents: Installation instructions Mounting instructions Other instructions MAY-dealer, name in block letters Signature Date/place Customer, name in block letters Signature Date/place Deutsch / English / Français...
