thomann the box pro Pyrit 10 User Manual page 21

Pyrit 15 (item no. 299646)
462 mm
397 mm
System
Configuration
Input connections
Output connections
Frequency range
Load capacity
Sensitivity (1 W/1 m)
Rated impedance
Max. sound pressure level
Max. short-term sound pressure
level
Beam angle (H × V)
Dimensions (W × H × D)
2-way full-range speaker
Woofer 1 × 15-inch speaker (ferrite)
with 75-mm voice coil
Tweeter 1 × 1.7-inch compression driver
(ferrite) with 44-mm voice coil
1 × Speaker Twist (2+/2–)
1 × Speaker Twist (2+/2–)
45 Hz...20 kHz, –3 dB
RMS: 350 W
Peak: 1400 W
97 dB SPL
8 Ω
128 dB SPL
127 dB SPL
60° × 90°
462 mm × 780 mm × 397 mm
Technical specifications
Pyrit 10, 12, 15
21
Passive Speaker
