Technical specifications

Pyrit 10 (item no. 299642)
306 mm
238 mm
System
Configuration
Input connections
Output connections
Frequency range
Load capacity
Sensitivity (1 W/1 m)
Rated impedance
Max. sound pressure level
Max. short-term sound pressure
level
2-way full-range speaker
Woofer 1 × 10-inch speaker (ferrite)
with 75-mm voice coil
Tweeter 1 × 1.4-inch compression driver
(ferrite) with 34-mm voice coil
1 × Speaker Twist (2+/2–)
1 × Speaker Twist (2+/2–)
55 Hz...20 kHz, –3 dB
RMS: 250 W
Peak: 1000 W
93 dB SPL
8 Ω
122 dB SPL
123 dB SPL
Technical specifications
Pyrit 10, 12, 15
15
Passive Speaker
