Summary of Contents for thomann the box pro Pyrit 10

Page 1 Pyrit 10, 12, 15 Passive Speaker...
Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 04.10.2024, ID: 299642, 299643, 299646 (V3)
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Symbols and signal words....................... 5 Safety instructions............................. 7 Features................................9 Installation..............................10 4.1 Tips on handling speakers......................13 4.2 Suspending the speaker........................ 14 4.3 Connections............................14 Technical specifications........................15 Plug and connection assignment....................25 Protecting the environment......................
Page 4 Pyrit 10, 12, 15 Passive Speaker...
Page 5: General Information
Our products and documentation are subject to a process of continuous development. They are therefore subject to change. Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document.
Page 6 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use.
Page 8 Safety instructions CAUTION! Risk of injury due to heavy weight! The device is heavy. Lifting and dropping it during transport and installation can cause injuries. Make sure at least two people work together when transporting and installing the device. NOTICE! Damage to the device if operated in unsuitable ambient conditions! The device can be damaged if it is operated in unsuitable ambient conditions.
Page 9: Features
Features Features Special features of this passive 2-way full-range speaker: Special features of the device: item no. 299642: 1 × 10-inch woofer, 1 × 1.4-inch tweeter item no. 299643: 1 × 12-inch woofer, 1 × 1.7-inch tweeter Item no. 299646: 1 × 15-inch woofer, 1 × 1.7-inch tweeter 2 ×...
Page 10: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively.
Page 11 Installation WARNING! Risk of injury due to improper installation! Improper mounting can lead to serious injuries and significant damage to prop‐ erty. When installing and operating, make sure to follow the standards and regulations that apply in your country. In Germany, this is DGUV regulation 17 “Staging and Production Facilities for the Entertainment Industry”.
Page 12 Installation NOTICE! Possible property damage to adjacent devices due to magnetic fields. Speakers generate a static magnetic field. This magnetic field can affect other neighbouring units and in unfavourable cases damage them. Ensure that speakers are always a sufficient distance away from sensitive equip‐ ment that may be affected by an external magnetic field.
Page 13: Tips On Handling Speakers
Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area.
Page 14: Suspending The Speaker
Installation 4.2 Suspending the speaker The speaker is equipped with M6 threads (item no. 299642) or M8 threads (item no. 299643 and 299646) at the top, bottom and sides, which allow it to be suspended from special holders (known as “flying” in the event technology business). Safety eyes can be screwed into these threads.
Page 15: Technical Specifications
Technical specifications Technical specifications Pyrit 10 (item no. 299642) System 2-way full-range speaker Configuration Woofer 1 × 10-inch speaker (ferrite) with 75-mm voice coil Tweeter 1 × 1.4-inch compression driver (ferrite) with 34-mm voice coil Input connections 1 × Speaker Twist (2+/2–) Output connections 1 ×...
Page 16 Technical specifications Beam angle (H × V) 60° × 90° Dimensions (W × H × D) 306 mm × 516 mm × 238 mm Weight 13.2 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Pyrit 10, 12, 15 Passive Speaker...
Page 17 Technical specifications Frequency response Pyrit 10, 12, 15 Passive Speaker...
Page 18 Technical specifications Pyrit 12 (item no. 299643) System 2-way full-range speaker Configuration Woofer 1 × 12-inch speaker (ferrite) with 75-mm voice coil Tweeter 1 × 1.7-inch compression driver (ferrite) with 44-mm voice coil Input connections 1 × Speaker Twist (2+/2–) Output connections 1 ×...
Page 19 Technical specifications Weight 20 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Pyrit 10, 12, 15 Passive Speaker...
Page 20 Technical specifications Frequency response Pyrit 10, 12, 15 Passive Speaker...
Page 21 Technical specifications Pyrit 15 (item no. 299646) System 2-way full-range speaker Configuration Woofer 1 × 15-inch speaker (ferrite) with 75-mm voice coil Tweeter 1 × 1.7-inch compression driver (ferrite) with 44-mm voice coil Input connections 1 × Speaker Twist (2+/2–) Output connections 1 ×...
Page 22 Technical specifications Weight 26.8 kg Ambient conditions Temperature range 0 °C…40 °C Relative humidity 20%…80% (non-condensing) Pyrit 10, 12, 15 Passive Speaker...
Page 23 Technical specifications Frequency response Pyrit 10, 12, 15 Passive Speaker...
Page 24 Technical specifications Further information Pyrit 10 (item no. 299642) Pyrit 12 (item no. 299643) Pyrit 15 (item no. 299646) Monitor inclination Ways 2-way 2-way 2-way Design Standard Standard Standard Truss-capable Colour Black Black Black Housing Plastic Plastic Plastic Stand flange 36 mm 36 mm 36 mm...
Page 25: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’...
Page 26: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packing material Environmentally friendly materials have been chosen for the packaging. These materials can be sent for normal recycling. Ensure that plastic bags, packaging, etc. are disposed of in the proper manner. Do not dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
Page 27 When disposing of the device, comply with the rules and regulations that apply in your country. You can also return your old device to Thomann GmbH at no charge. Check the current conditions on www.thomann.de.
Page 28 Notes Pyrit 10, 12, 15 Passive Speaker...
Page 29 Notes Pyrit 10, 12, 15 Passive Speaker...
Page 30 Notes Pyrit 10, 12, 15 Passive Speaker...
Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
