Technical specifications
Pyrit 12 (item no. 299643)
368 mm
349 mm
Pyrit 10, 12, 15
18
Passive Speaker
System
Configuration
Input connections
Output connections
Frequency range
Load capacity
Sensitivity (1 W/1 m)
Rated impedance
Max. sound pressure level
Max. short-term sound pressure
level
Beam angle (H × V)
Dimensions (W × H × D)
2-way full-range speaker
Woofer 1 × 12-inch speaker (ferrite)
with 75-mm voice coil
Tweeter 1 × 1.7-inch compression driver
(ferrite) with 44-mm voice coil
1 × Speaker Twist (2+/2–)
1 × Speaker Twist (2+/2–)
50 Hz...20 kHz, –3 dB
RMS: 300 W
Peak: 1200 W
97 dB SPL
8 Ω
127 dB SPL
126 dB SPL
60° × 90°
368 mm × 630 mm × 349 mm
