- Page 1 PA12ECO MKII passive full-range speaker user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 27.10.2015, ID: 223280...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 6 Features................................8 Installation..............................9 4.1 Tips on handling speakers......................11 4.2 Connections............................12 Technical specifications........................15 Protecting the environment......................16 PA12ECO MKII... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual. - Page 5 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in minor injury if it is not avoided.
-
Page 6: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used in a sound reinforcement system. Use the device only as described in this user manual. Any other use or use under other operating conditions is consid‐ ered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 7 Safety instructions CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
-
Page 8: Features
Features Features Special features of this powerful passive full-range speaker box: 1 × 12" woofer, 1 × 3" cone tweeter 2 × lockable 1/4"/NL4 combo sockets (1+/1–) Wooden cabinet with felt cover Robust protective grille Tripod mounting flange passive full-range speaker... -
Page 9: Installation
Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 10 Installation NOTICE! Use of stands When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does not exceed the maximum permissible load capacity of the stand. passive full-range speaker...
-
Page 11: Tips On Handling Speakers
Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. -
Page 12: Connections
Installation 4.2 Connections passive full-range speaker... - Page 13 Installation 1 INPUT A 1/4" / NL4 combo socket (1+/1–) serves as input. 2 OUTPUT A 1/4" / NL4 combo socket (1+/1–) serves as output for another passive speaker. NL4 mounting connectors for The drawing alongside shows the pin assignment of the lockable NL4 mounting connectors. speaker connections PA12ECO MKII...
- Page 14 Installation Phone plugs for speaker con‐ Drawing and table indicate the pin assignment of a 1/4" TS phone plug. nections Signal Ground, shielding passive full-range speaker...
-
Page 15: Technical Specifications
Technical specifications Technical specifications System Passive 2-way full-range speaker box with built-in crossover Speakers 1 × 12" woofer, 1 × 3" tweeter Power handling 140 W (RMS), 560 W (Peak) Impedance 8 Ω Maximum SPL (1 m) 113 dB Frequency response 65 Hz …... -
Page 16: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 17 Notes PA12ECO MKII...
