Cudy FS1026PS1 Quick Installation Manual

1 Hardware Connection
Power Socket
1 2
Power input:
AC100-240V 1 2 3
2
Specifications
Model GS1026PS1
IEEE802.3 / IEEE802.3u / /IEEE802.3x
Network Protocol
IEEE802.3ab / IEEE802.3z
IEEE802.3af /IEEE802.3at
PoE Standard
Max each port 15.4W ( IEEE 802.3af )
30W ( IEEE 802.3at )
Max each port：
PoE compatibility IEEE 802.3af/at adaptive
PoE port output DC48-55V
Power over spare pairs 1/2(+) , 3/6 (-)
Power Pin
10BASE-T: Cat 6 UTP(≤250 meter)
Network Media 100BASE-TX: Cat5 or more UTP (≤100 meter)
1000BASE-TX: Cat5 or more UTP (≤100 meter)
3 4 5 6 7 8 9 10
4 5 6 7 8 9 10 11
IP Camera
11 12 13 14 15 16 17 18
OFF
VLAN Extend
(1-24) (9-24)
12 13 14 15 16 SW 17 18
Internet
Optical
Performance Specification
Power Supply
Product Dimension
Package Dimension
Powered Device (PD)
Wireless AP Smart VoIP
G25
19 20 21 22 23 24
19 20 21 22 23 24 PWR G26
Router
MultiMode Fiber: 850nm, 1310nm,
Transmission Distance: 550m/2Km
Single-Mode Fiber: 1310nm, 1550nm,
Transmission Distance: 20/40/60/80/100/120km
Bandwidth: 10.8Gbps
MAC: 2K
Packet Buffer Memory: 1M
Packet Forwarding Rate: 8Mpps
Power input: AC100-240V 50/60Hz,
Output: 52V5.76A, Power Budget: 300W
320mm*210mm*46mm
370mm*275mm*85mm
24-Port 10/100M PoE+ Switch with 2
Gigabit Uplink Ports and 1 Gigabit SFP Slot
FS1026PS1
G27
SFP Slot
NVR
Monitor
