VLT® Programmable I/O MCB 115
Installation Guide
2
1
5
Illustration 1: Installation in Enclosure Sizes A2, A3, and B3
1 LCP
2 Terminal cover
3 Slot B

3.3 Mounting the Option in Enclosure Sizes A5, B1, B2, B4, C, D, E, and F

The installation procedure depends on the enclosure size of the drive. This procedure is for installation in enclosure sizes A5, B1, B2,
B4, C, D, E, and F.
Procedure
1. Remove the LCP and the LCP cradle.
Fit the option card into slot B.
2.
3. Connect the control cables and relieve the cable. See
Fit the cradle on the drive.
4.
5. Fit the LCP in the cradle.
8 | Danfoss A/S © | 2020.08
3
4
3.4.1 Speci cations
4 Option
5 LCP frame
for wiring details.
AN295938195323en-000201 / 130R0655
Installation
