Use flexible tubing, which comply with
the BS.669 current edition.
A
B
C
WARNING!
The gas bayonet connector must be in
the marked area.
Dimension
A
B
C
D
E

3.8 Pressure test

Use a semi rapid injector for the pressure
test.
1. Connect a pressure gauge to the semi
rapid injector.
2. Check the supply pressure by fully turning
on the semi rapid burner, and any other
burner and lighting them. For natural gas,
the pressure must be 20 mbar.
3. Turn off the taps and disconnect the
pressure gauge.
4. Make sure that all burners work properly.
3.9 Checking the hob burners
1. Lift the lid.
10 ENGLISH
2. Put on the burner crowns and caps. Make
3. Put on the pan supports.
4. Light one of the hob burners.
5. Turn the knob for the hob to the off
3.10 Checking the oven burners
1. Put in the deep pan and the trivet.
E
2. Light the oven burner.
D
3. Turn the knob to the off position.
C
3.11 Checking the Lid Safety Device
1. Lift the lid.
2. Light one of the hob burners.
3. Close the lid. There should be no gas
mm
4. Turn the knob to the off position and lift
250
680
50

3.12 Electrical installation

250
580
The manufacturer is not responsible if
you do not follow the safety precautions
from Safety chapters.
This appliance is supplied with a main plug
and a main cable.
The spark generator is active all the time
if the phases are not connected correctly.
The power cable must not touch the part
of the appliance shaded in the illustration.
sure that they are correctly seated.
To light the hob burner refer to the
"Ignition of the hob burners".
Check if the flame is regular.
Check each of the burners.
position.
To light the oven burner refer to the
"Ignition of the oven burners".
Check if the flame is regular.
To light the hob burner refer to the
"Ignition of the hob burners".
supply to the hob burners. The burner
goes out.
the lid. The gas supply should be restored
to the hob burners, when you turn the
knob on.
WARNING!
WARNING!
