Summary of Contents for STA-RITE MAX-E-PRO
- Page 1 MAX-E-PRO® POOL AND SPA PUMP INSTALLATION AND USER’S GUIDE IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS...
-
Page 2: Important Pump Warning And Safety Instructions
This hazard is present it is capable of being readily disassembled for storage and reassembled when the drain cover is missing, loose, cracked, or not properly secured. to its original integrity. MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®... - Page 3 Observe filter pressure gauge and be sure it is not higher than the pre-service condition. MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®...
-
Page 4: Table Of Contents
Suction Outlet Covers Motor/Impeller/Diffuser Table Testing and Certification Water Velocity Electrical Installation Wiring Grounding Bonding Operation ..............Pressure Test Priming the Pump Draining Pump Winterizing Start-up for Winterized Equipment Performance Curves MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®... -
Page 5: Installation
Use at least 2” (51mm) pipe. Increase size if a long run is needed. and pump wiring. Support both the suction and discharge piping independently, Be sure the Max-E-Pro Pool and Spa Pump equipment placing these supports as close to the pump as possible. This will ®... -
Page 6: Suction Requirements
(see Figure 2). More than one pump can be connected to a single suction line as long as the requirements above are met. Figure 2 MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®... -
Page 7: Electrical Installation
Motor Shaft with a Pentair salt chlorine generator. Flats for 1/4” Allen Wrench MAX-E-PRO Pool and Spa Installation and User’ s Guide ®... -
Page 8: Operation
Note: If pump does not prime, make sure that all valves are open, suction pipe end is under water, and that there are no leaks in suction pipe. See Troubleshooting, page 8. MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®... -
Page 9: Winterizing
50Hz Performance 60Hz Performance Flow, m3/h Flow, gpm Performance Curve Key Performance Curve Key 50Hz 60Hz AP5P6R6D-E3 AP5P6R6G-E3 AP6EA6E-E3 AP5P6R6D3-E3 AP5P6R6G3-E3 AP6EA6F-E3 AP5P6R6E-E3 AP5P6R6H-E3 AP6EA6G-E3 AP5P6R6E3-E3 AP5P6R6H3-E3 AP6EAA6G-E3 AP5P6R6F-E3 AP6E6H-E3 AP5P6R6F3-E3 MAX-E-PRO Pool and Spa Installation and User’ s Guide ®... -
Page 10: Maintenance
12. Place seal plate face down on a flat surface and tap out white ceramic seal (see Figure 4). 13. Clean the seal plate’s seal cavity and the motor shaft. Figure 4 MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®... -
Page 11: Pump Reassembly/Installing New Seal
11. Open all gate valves in the suction and discharge lines. 12. Reconnect power to the pump at the circuit breaker. 13. Prime the pump according to Priming the Pump, on page 4. MAX-E-PRO Pool and Spa Installation and User’ s Guide ®... -
Page 12: Troubleshooting
TROUBLESHOOTING Read and understand all safety and operating instruction in this manual before servicing the Max-E-Pro Self-Priming ® Pool/Spa Pump. Only qualified personnel should electrically test the pump motor. Problem Possible Cause Corrective Action Failure to Pump Suction leaks / lost Ensure pump volute and strainer basket are full of water. -
Page 13: Replacement Parts
Lock Washer, #8 APU30-922SS Screw (w/C1-271P Diffuser) APU30-542SS Screw (w/C1-271P1 Diffuser) Trap Body Assembly (Incl. Item# 15-18) NPT AP17307-0110 internal thread Trap Body Assembly (Incl. Item# 15-18) BSP AP17307-0110W internal thread MAX-E-PRO Pool and Spa Installation and User’ s Guide ®... -
Page 14: Motor/Impeller/Diffuser Table
C105-238PGA 37337-6081 C1-271P AP5P6R6F3-E3 1-1/2 APMPS1503V550BE3 C105-238PECA 37337-6080 C1-271P AP5P6R6G3-E3 APMPS2003V550BE3 C105-238PLBA 37337-6080 C1-271P AP5P6R6H3-E3 APMPS3003V550BE3 C105-238PHA 37337-6081 C1-271P (*) Note: Pump model does not use an impeller screw MAX-E-PRO Pool and Spa Pump Installation and User’ s Guide ®... - Page 15 Distribution and Service by: (Distributor Stamp Here) Date of Purchase: 371 He Shan Rd., New District Suzhou, Jiangsu 215011, China. WWW.PENTAIR.COM © 2022 Pentair Water Pool and Spa, Inc. All rights reserved. This document is subject to change without notice. P/N APS691 REV.
