Technical Data; Unpacking; Assembly - Scheppach PM1200 Translation Of Original Instruction Manual

Residual risks
m The machine has been built according to the state-
of-the-art and the recognised technical safety require-
ments. However, individual residual risks can arise
during operation.
• Danger of injury for fingers and hands due to the ro-
tating stirrer.
• Hazard due to electrical power with the use of im-
proper electrical connection cables.
• Furthermore, despite all precautions having been
met, some non-obvious residual risks may still re-
main.
• Residual risks can be minimised if the "Safety in-
structions" and "Intended use" are observed along
with the complete operating instructions.

6. Technical data

Rated voltage
Power consumption
Speed
Weight
Stirrer receptacle
Mixing rod (with mixing element)
(2) Ø max.
Acoustic emission
Noise emission values measured according to the rel-
evant standards.
Sound pressure level L
pA
Uncertainty K
pA
Sound power level L
wA
Uncertainty K
WA
Vibration a
h
Uncertainty K
• The specified vibration emission value has been
measured according to a standardised testing pro-
cedure and can be used for comparison of one elec-
tric tool with another;
• The specified vibration emission value can also be
used for an initial estimation of the exposure.
• The vibration emission value can vary from the
specified value during the actual use of the electric
tool, depending on the type and the manner in which
the electric tool is used;
22 | GB
• Try to minimise stress from vibrations as low as
7.
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
220-240 V~ 50Hz
• If possible, keep the packaging until the expiry of the
1200 Watts
0-700 rpm
• Familiarise yourself with the product by means of the
5.7 kg
• With accessories as well as wearing parts and re-
M14
120 mm
• When ordering please provide our article number as
m WARNING!
The product and the packaging material are not
children's toys! Do not let children play with plas-
tic bags, films or small parts! There is a danger of
89 dB
choking or suffocating!
3 dB

8. Assembly

100 dB
3 dB
m Attention!
5.67 m/s²
Always make sure the product is fully assembled
1.5 m/s²
before commissioning!
1.
2.
m DANGER!
Only use a mixing rod that is suitable and de-
signed for the material to be mixed. An incorrect
mixing rod can damage the device due to over-
loading and cause accidents!
www.scheppach.com
possible. Some examples of means for reducing the
vibration stress are wearing gloves while using the
tool and limiting work time. In the process all parts
of the operating cycle must be taken into account
(such as times in which the electric tool is switched
off or time in which it is switched on, but is not run-
ning under a load).

Unpacking

aging and transport safety devices (if present).
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
warranty period.
operating manual before using for the first time.
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
well as type and year of manufacture for the product.
Turn the mixing rod (1) clockwise into the mixing
element (2) (Fig. 2).
Then screw the assembled mixing rod into the
drive shaft (3) (Fig. 3).
