• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
7

Technical data

Cordless jigsaw
Engine voltage
Idle speeds n
0
Pendulum stroke levels
Saw stroke
Depth of cut in wood
Depth of cut in metal
Cutting angle right/left
Weight (without battery)
Subject to technical changes!
Noise and vibration
WARNING
Noise can have serious effects on your health. If the
machine noise exceeds 85 dB, please wear suitable
hearing protection for you and persons in the vicinity.
The noise and vibration values have been determined in
accordance with EN 62841-1.
Noise data
Sound pressure level L
pA
Measurement uncertainty K
Sound power level L
wA
Measurement uncertainty K
Vibration parameters
Vibration a
h
in wood
Measurement uncertainty K
in metal
Measurement uncertainty K
The total vibration emission values specified and the de-
vice emissions values specified have been measured in
accordance with a standardised test procedure and can
be used for comparison of one electric tool with another.
The total noise emission values specified and the total vi-
bration emission values specified can also be used for an
initial estimation of the load.
20 | GB
BC-JS254-X
20 V
1000 - 3000
1-3 and fine cut setting 0
25.4 mm
max. 100 mm
max. 10 mm
0° - 45°
1.8 kg
86 dB
5 dB
pA
94 dB
5 dB
wA
5.677 m/s
1.5 m/s
6.627 m/s
1.5 m/s
www.scheppach.com
WARNING
The noise emission values and vibration
emission value can vary from the specified
values during the actual use of the power
tool, depending on the type and the manner
in which the electric tool is used, and in par-
ticular the type of workpiece being pro-
cessed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
rpm
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
8

Assembly

CAUTION
Danger of injury!
Do not insert the battery until the battery-powered tool
is ready for use.
8.1 Attaching/taking off the sliding
shoe (19) (Fig. 2)
When working on workpiece surfaces that are susceptible
to scratches, it is recommended to work with a sliding
shoe (19).
8.1.1 Attaching the sliding shoe
1. Place the sliding shoe (19) at the front of the base
plate (7).
2. Now press the latches (19a) on the rear part of the
sliding shoe (19) over the base plate (7).
8.1.2 Taking off the sliding shoe
1. Push the sliding shoe (19) off the base plate (7) at the
latches (19a).
2. Take the sliding shoe (19) off the base plate (7) to-
wards the front.
2
8.2 Inserting/removing the tool
attachment (Fig. 3)
2
2
WARNING
2
Tool attachments may be sharp and become hot during
use. Always wear protective gloves when handling the
tool attachments.
CAUTION
Keep your hands away from the tool attachment when
the product is in operation.
Note:
Only saw blades with a T-shaft mounting (single-cam
shank) such as the saw blade supplied can be used.
8.2.1 Inserting the saw blade
Note:
Ensure that the right saw blade for the material in ques-
tion is always used.
