Remaining hazards
The machine has been built using mod-
ern technology in accordance with rec-
ognized safety rules. Some remaining
hazards, however, may still exist.
• The splitting tool can cause injuries to fin-
gers and hands if the wood is incorrectly
guided or supported.
• Thrown pieces can lead to injury if the
work piece is not correctly placed or held.
• Injury through electric current if incorrect
electric connection leads are used.
• Even when all safety measures are taken,
some remaining hazards which are not
yet evident may still be present.
• Remaining hazards can be minimized by
following the safety instructions as well as
the instructions in the chapter Authorized
use and in the entire operating manual.

7. Technical data

Dimensions D/W/H
Table height mm
Working height mm
Log length cm
Log width min./max. cm
Power max. tons*
Piston stroke cm
Forward speed cm/s
Return speed cm/s
Oil quantity litres
Weight kg
Motor V/Hz
Input P1 W
Output P2 W
860/550/1100-
1650
70/545/830
950
61,5 / 89 / 137
12 - 40
10
55
5,2 3,3
22 16
7
157
400/50 230/50
3300 3150
2400
Operating mode
Motor speed 1/min
Phase inverter
Noise
m WARNING: Noise can have serious ef-
fects on your health. If the machine noise
exceeds 85 dB (A), please wear suitable
hearing protection.
Sound power level in dB
L = 88 dB (A)
wa
Sound pressure level in dB
L = 79 dB (A)
pa
A measurement uncertainty surcharge K =
4 dB applies to the emission values stated.

8. Unpacking

• Open the packaging and remove the de-
vice carefully.
• Remove the packaging material as well
as the packaging and transport bracing
(if available).
• Check that the delivery is complete.
• Check the device and accessory parts
for transport damage.
• In case of complaints the dealer must be
informed immediately. Subsequent com-
plaints will not be accepted.
• If possible, store the packaging until the
warranty period has expired.
• Read the operating manual to make your-
self familiar with the device prior to using
it.
S6 40%
2800
yes -
