Item #1011142253
Model ARFL80CE
Basic Model # AI-ARFL80CE-Rev1-03012024
USE AND CARE GUIDE
LED WALL OR FLOOD LIGHT
Questions, problems, missing parts?
Before returning to the store, call Commercial Electric Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED Wall/Flood Light. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Commercial Electric!
Advertisement
Table of Contents
Related Manuals for Commercial Electric ARFL80CE
Summary of Contents for Commercial Electric ARFL80CE
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Commercial Electric through the purchase of this LED Wall/Flood Light. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home...
-
Page 2: Table Of Contents
Table of Contents Safety Information ........2 Installation . -
Page 3: Warranty
Warranty 5-YEAR LIMITED WARRANTY This is a limited warranty offered by the manufacturer for a period of five years from the date of purchase to its customers. The manufacturer warrants to customers that the products will be free from defects in material and workmanship. The obligation of the manufacturer under this warranty is limited to the provision of replacement of products and is extended to the original purchaser of the product on presenting valid purchase receipt or other proof of date of original purchase acceptable to the manufacturer. -
Page 4: Pre-Installation
Pre-Installation PLANNING INSTALLATION Before installing the light fixture, ensure that all parts are present. Compare parts with the hardware Included and Package contents sections. If any part is missing or damaged, do not attempt to assemble, install or operate this light fixture. Estimated installation time: 20 minutes Mount plate and Cover (included) REVIEW THIS INFORMATION TO ENSURE A SUCCESSFUL... -
Page 5: Hardware Included
Pre-Installation (continued) HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity Part Description Quantity #8-32 x 3/4 in. Philips 1/2 in. Wing nut for wall mounting bracket screw mount plate P3 Wire nut M20 Lock washer L2.5 Allen key 1/2 in. -
Page 6: Installation
Installation Turning off the electricity □ Verify the wall switch is in the OFF position. □ Turn OFF power at the circuit breaker that supplies power to the outlet box you are working on. □ For screw-in type fuses unscrew the fuse that supplies power to the outlet box you are working on WARNING: Risk of electric shock. - Page 7 Installation (continued) Attaching the mounting plate to junction box Only applicable for wall/eave mount if using the base plate IMPORTANT: Only unscrew the hex plate bolts (E) far enough to remove the mounting plate (D). Do not fully remove the hex plate bolts (E).
- Page 8 Installation (continued) Securing the fixture and wiring Wall/Eave Mount □ Once the fixture is wired,place the fixture on the mounting plate (D) and use the hex bolts (E) to tighten the fixture on the plate (D) by using the allen key (CC). □...
-
Page 9: Operation
Operation Selecting light color temperature & FAO setting FAO/Lumen CCT selection selection 3000K 3500K □ Before installation, unscrew the plug at the back of the fixture and 8200lm 4000K access the CCT (light color temperature) and FAO (lumens) switches 6000lm 5000K 4200lm □... -
Page 10: Care And Cleaning
Care and Cleaning □ Shut off the main power supply before cleaning the product. To prolong the original appearance, clean the light fixture with clean water and a soft, damp cloth only. □ Do not use abrasive cleaners or cleaners that contain alcohol. Do not apply paints, solvents or any other chemicals on this light fixture. - Page 11 Questions, problems, missing parts? Before returning to the store, call Commercial Electric Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. Document #: ARFL80CE...
