- Page 1 Yale Smart Living User Installation Guide...
-
Page 2: Table Of Contents
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE Contents Introduction Conexis™ L1 Smart Door Lock User Requirements Getting to Know Your Conexis™ L1 Smart Door Lock 5 What Has Been Installed? Select Your Preferred Opening Method What You Need to Do: Step by Step Guide Using Your Conexis™... -
Page 3: Introduction
Introduction This guide provides you with step by step instructions on how to use your new Yale Smart Living products. The range comprises the Yale Conexis™ L1 Smart Door Lock which provides the freedom to secure homes without the need for a conventional key. The range also includes a Digital Door Viewer (DDV) providing a safe way to identify visitors. -
Page 4: Conexis™ L1 Smart Door Lock
A Smart Phone with Bluetooth capability. Download of the Yale Smart Living Lock App onto Smart Phone. If you don’t have the Yale Smart Living Lock application just yet, don’t worry as this is carried out in the step by step procedure. -
Page 5: Getting To Know Your Conexis™ L1 Smart Door Lock
Getting to know Inside your Conexis™ L1 Smart Door Lock Radio Cover Inside Light Lever Handle Thumbturn Battery Cover Outside Tag Reader Bluetooth Wakeup Button and Light Lever Handle Backup 9V Battery Contacts... -
Page 6: What Has Been Installed
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What has been Your installation team will have carried out the following installed? whilst installing the product in your home. 1. Fitting of the Conexis™ L1 Smart Door Lock 2. -
Page 7: What You Need To Do: Step By Step Guide
On your Smart Phone navigate to your app store. guide IOS 9.0 onwards Android 4.3 onwards Search for “Conexis L1”. Conexis L1 Download the Yale Smart Living Lock app Open the Yale Smart Living Lock app on your Smart Phone. - Page 8 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Click “Not Signed Up Yet?”. do: step by step guide Register yourself through completion of the User Registration form.
- Page 9 What you need to Create a Mobile Key do: step by step Please ensure that Bluetooth is turned on, on your Smart Phone. guide Within the App press, “Add New Lock”. Choose a name for your Key/Lock. (e.g. Front Door), then press “OK”.
- Page 10 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to When prompted by App please complete the following do: step by step steps. On the interior handle lift up and off the upper casing.
- Page 11 What you need to Press the purple light button to wake up the Bluetooth. do: step by step guide The light will turn blue. Place your phone next to the reader on the external handle.
-
Page 12: Using Your Conexis™ L1 Smart Door Lock With Smart Phone App And Key Tags
Smart Phone App and Key Tags Now that you’ve got your app all set up and ready to go, it’s time to re-register your Key Tags. (Ensure you have all your Key Tags available). Open the Yale Smart Living Lock app on your Smart Phone. - Page 13 What you need to Navigate to the lock menu by clicking the lock icon, do: step by step then select “Cards/Tag”. guide Select “New Card/Tag” at the bottom of the screen.
- Page 14 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Enter a name for the Smart Key Tag. do: step by step (e.g. Joe Bloggs’ Key) guide Press the Bluetooth wakeup button on the exterior handle when prompted by App.
- Page 15 What you need to When the light turns purple hold the relevant Key Tag up do: step by step to the Key Tag reader. guide The light will turn green and a “Beep Beep” will sound to confirm the addition of the Key Tag.
-
Page 16: Using Your Conexis™ L1 Smart Door Lock With Key Tags Only
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Using Your Conexis™ L1 Smart Door Lock with Key Tags ONLY do: step by step As you’ve opted to use Key Tags only, there’s no need to guide install the Smart Phone App. - Page 17 What you need to Press the “R” button to make the Conexis™ L1 Smart do: step by step Door Lock enter “Learn” Mode. guide The exterior handle will show a purple light Adding Tags in this way will delete any existing Tags. Present the Key Tag to the Key Tag Reader on the external handle.
- Page 18 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Hold the next Key Tag up to the Key Tag Reader, again do: step by step a “Beep Beep” will sound to confirm the Key Tag has been accepted and set.
- Page 19 What you need to do: step by step guide Close and Lock the Door. Present the Key Tag to the Key Tag Reader and confirm if the door has been unlocked. Repeat for all key tags. If for any reason that a Key Tag hasn’t been registered accordingly, please repeat the steps from step 1 onwards.
-
Page 20: Unlocking The Door With Key Tag
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Unlocking the Door with Key Tag do: step by step Present Key Tag within a few millimetres of the Key Tag Reader. guide Push down lever handle to open door. -
Page 21: Unlocking The Door With Mobile Key
Unlocking the Door with Mobile Key do: step by step Ensure that Bluetooth is turned on, on your Smart Phone and that the Yale Conexis App is running in the guide background of your phone. If you have closed the App fully simply open and select the mobile key you previously set up. - Page 22 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Present your smart phone to the Conexis™ L1 Smart do: step by step Door Lock, turn your smart phone 90 degrees clockwise, and then turn back 90 degrees to vertical position.
-
Page 23: Locking The Door
What you need to do: step by step guide Locking the Door Close the door. Lift the handle fully up. The lock will engage and confirm by three beeps, followed by a pause and then a further three beeps. Check the door is locked, by pressing down on the lever handle. -
Page 24: Sending A Mobile Key
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Sending a Mobile Key do: step by step Only the key owner/administrator can send a temporary or permanent key to family and friends through the guide Conexis App. - Page 25 What you need to Click on “Invite user to access these locks”. do: step by step guide Enter the contact name or email address of the person you wish to send a key to and enter.
- Page 26 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Confirm if you would like to schedule a key or send do: step by step a permanent key for the person. guide If creating a temporary mobile key, select the times and dates you wish to have the key scheduled for, then click “Issue Key”.
- Page 27 What you need to Verify password to share this key. do: step by step guide The person receiving the mobile key must tap on the key to accept it.
-
Page 28: Digital Door Viewer
The Yale DDV can also store up to 50 images on its optional internal memory whilst you are away from home, with time and date stamps. A Micro SD card (not included), can be installed to add further memory. -
Page 29: Getting To Know Your Ddv
Digital Door Getting to Know Your DDV Viewer Night Vision Camera Door Bell Menu Button Battery Compartment Power Button 4 inch LCD Screen Door Bell Speaker... -
Page 30: What You Need To Do: Step By Step Guide
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Setting up Your DDV do: step by step Please ensure you have the current time and date handy for this process. guide Slide open the battery compartment and insert the batteries provided paying close attention to the format shown on the inside of the battery compartment cover. - Page 31 What you need to do: step by step guide Select the relevant hour (24hrs) by using the arrow buttons to go up or down as appropriate. Press the menu button to set the hour. The minute will begin flashing. Select the relevant minute by using the arrow buttons to go up or down as appropriate.
- Page 32 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to do: step by step guide Select the volume of the doorbell you wish, using the arrow buttons to increase or decrease the volume as appropriate.
- Page 33 What you need to do: step by step guide Reset the time if appropriate. Leave the DDV, and the external image will appear. Your DDV setup is now complete.
-
Page 34: Using Your Ddv
YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Using Your DDV do: step by step Visitors to Your Home guide When a visitor comes to your home they will press the doorbell. - Page 35 What you need to Reviewing the DDV Photo Album do: step by step A photo will be taken of a visitor each time they ring the door bell, with a date and time stamp so you can guide view who has visited your property whilst you have been away.
- Page 36 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE What you need to Managing the DDV Photo Album do: step by step In order to conserve memory and ensure there is enough storage for future photos of visitors, it’s important that...
-
Page 37: Ongoing Support
Yale Helpline on 01902 364606 or email info@yale.co.uk. The Yale helpline is open from Monday to Friday from 8:30am to 5:30pm. Out of Hours In case of emergency such as being unable to access your property, we will be on hand to help, contact the emergency line on 0800 078 7022. - Page 38 YALE SMART LIVING USER INSTALLATION GUIDE YALE SMART LIVING USER INSTALLATION GUIDE Notes...
- Page 39 Notes...
- Page 40 YALE SMART LIVING USER INSTALLATION GUIDE Registered office: Anglian Windows Limited, Liberator Road, Norwich NR6 6EU. Registered in England No. 2540020. Anglian Home Improvements is a trading name of Anglian Windows Limited. www.anglianhome.co.uk Anglian Home Improvements policy is one of continued development and in accordance with this, we reserve the right to amend specification of our products as their development dictates.
