  • Page 1     2N Access Unit M Installation Manual             v.1.3 www.2n.com...

  • Page 2: Table Of Contents

    2.2.2 Installation in Flush Mounting Box • 2.2.3 Installation on Mounting Backplate • 2.3 Electric Installation • 2.4 Extending Module Connection • 3. Detection of 2N Access Unit M using 2N® Network Scanner • 4. Factory Reset • 5. Maintenance • 6. Status Signaling •...

  • Page 3: Product Overview

    The installation of 2N Access Unit M is very easy. All you have to do is connect the system to your LAN via a mains cable. Feed the access system either from a 12V power supply or your PoE supporting LAN.

  • Page 4: Components And Associated Products

    TFTP/HTTP client for automated firmware and configuration upgrade and update 1.1 Components and Associated Products Main Units • 2N Access Unit M 13.56 MHz, NFC ready, 3 m LAN cable version • is used for reading RFID cards in the 13.56 MHz bandwidth with the 2N Part No.
  • Page 5 2N Access Unit M Installation Manual Main Units • 2N Access Unit M RFID 125 kHz, 13.56 MHz, NFC, 3 m LAN cable version 2N Part No. • is used for reading RFID cards in the 125 kHz and 13.56 MHz 9161141 bandwidths with the NFC support.
  • Page 6 2N Access Unit M Installation Manual Main Units • 2N Access Unit M Bluetooth & RFID 125 kHz, 13.56 MHz, NFC, 3 m LAN cable version 2N Part No. • is used for reading RFID cards in the 125 kHz and 13.56 MHz 9161151 bandwidths with the NFC support.
  • Page 7 2N Access Unit M Installation Manual Main Units • 2N Access Unit M Touch Keypad & RFID 125 kHz, 13.56 MHz, NFC, 3 m LAN cable version 2N Part No. • is used for reading RFID cards in the 125 kHz and 13.56 MHz 9161161 bandwidths with the NFC support.
  • Page 8 2N Access Unit M Installation Manual Mounting Accessories 2N Part No. • Flush mounting box for walling-in 916121 • For cable connection and safekeeping under the access unit Axis Part No. 02940-001 2N Part No. • Surface mouting box 916122 •...

  • Page 9: Electric Locks

    2N Access Unit M Installation Manual Electric Locks Part No. 11202101 • Mini electronic doorstrike series 5  • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular • short sheet metal front cover version (130 mm) •...
  • Page 10 2N Access Unit M Installation Manual Part No. 11202102-L • Mini electronic doorstrike series 5 – with momentum pin, long • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular •...
  • Page 11 2N Access Unit M Installation Manual Part No. 11202104 • Mini electronic doorstrike series 5 – door signaling • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular •...
  • Page 12 2N Access Unit M Installation Manual Part No. 11202105-L • Mini electronic doorstrike series 5 – fail-safe, long • electric opener designed for door frame installation • intended for such narrow profiles as aluminum, wood or PVC in particular •...
  • Page 13 Electromechanical lock SAM 7255 • 72/55 self-locking lock with panic function • A key is necessary for door opening from the outside (or an electric pulse from a connected 2N IP intercom / reader). • convenient solution for emergency exits Part No.
  • Page 14 • 92/35 self-locking lock with panic function • A key is necessary for door opening from the outside (or an electric pulse from a connected 2N IP intercom / reader). • convenient solution for emergency exits Part No. 11202301 •...
  • Page 15 2N Access Unit M Installation Manual Part No. 11202303 • Cable protector FX300G • Provides secure passage and protection of the supply cable between the door frame and the door leaf. • 440 mm length Part No. 11202304 • Cable protector FX500G •...
  • Page 16 • applicable for right / left doors • in / out opening versions  • FAQ: Electric locks – Differences between locks for 2N IP access systems 16 /  67...
  • Page 17 2N Access Unit M Installation Manual Power Supply • PoE injector – without cable • PoE injector – with EU cable Part Numbers • PoE injector – with US cable 91378100E • For intercom supply via Ethernet cable where the PoE switch is absent.
  • Page 18 2N Access Unit M Installation Manual Additional Modules • Security Relay • A handy add-on that significantly enhances door entry security 2N Part No. Prevents lock tampering. Installed between the intercom, from which 9159010 it is also supplied, and the lock to be controlled.
  • Page 19 2N Access Unit M Installation Manual Additional Modules • RFID card, MIFARE Classic 1k, 13.56 MHz 2N Part No. 9134173 Axis Part No. 01384-001 • RFID fob, MIFARE Classic 1k, 13.56 MHz 2N Part No. 9134174 Axis Part No. 01385-001 •...
  • Page 20 • RFID fob, type EM4100, 125 kHz 2N Part No. 9134166E Axis Part No. 01396-001 2N Part • 2N RFID card Mifare Desfire EV3 4K 13.56MH 10 pcs No. 11202601 • 10 pcs per package • MIFARE DESFire EV3 (ISO/IEC14443A) Axis Part •...
  • Page 21 External RFID card reader connectable to a PC via a USB interface. 9137421E Suitable for system administration and adding 13.56 MHz, 125 kHz Axis Part No. cards and Android platform devices supporting NFC/HCE using 2N IP 01400-001 intercom web interface or 2N Access Commander. Suitable for MIFARE DESFire card upload to the 2N PICard...
  • Page 22 Suitable for system administration and adding 13.56 MHz, Axis Part No. 125 kHz cards and Android platform devices supporting NFC/HCE 01527-001 using the 2N IP intercom web interface or 2N Access Commander. Suitable for MIFARE DESFire card upload to the 2N PICard Commander encryption application.
  • Page 23 IP device. You do not have to configure anything, all you need is one 2N 2Wire unit at each end of the cable and a power supply connected to at least one of these units.

  • Page 24: Terms And Symbols

    InformaCast 2N Part No. 9137910 Axis Part No. 01381-001  • Refer to the local 2N distributor for more accessories and recommendations please. 1.2 Terms and Symbols The following symbols and pictograms are used in the manual:  Safety •...

  • Page 25: Description Of Installation

    2.2 Mechanical Installation ®  Access Unit M is designed for surface or flush mounting. Electrical mouting boxes for cable connection and placement under the unit are available in both the surface and flush versions. These boxes are not part of the main unit package.

  • Page 26: General Mounting Principles

    Any intentional mechanical damage to the device (drilling, main unit tampering, etc.) results in a loss of warranty. 2.2.1 Surface Mounting Access Unit M in the basic package without accessories is designed for surface mounting (wall, plasterboard, door frames). 26 /  67...
  • Page 27 2N Access Unit M Installation Manual Use the drilling template shown on the device box to prepare holes of the required sizes for cabling and dowels on the selected place in the required height. Feed the cables out of the pre- predrilled hole.
  • Page 28 Then fit the holder through the dedicated holes using the screws enclosed. Interconnect the fed-out cables with the 2N Access Unit M cabling. Put the device carefully on the installed holder from above downwards and fix its position on the holder carrying elements by tightening the screw from the bottom through the holder hole. ...

  • Page 29: Mounting Procedure

    2N Access Unit M Installation Manual  Note • Shortening of the LAN cable in Part Nos. 9161121, 9161141, 9161151, 9161161 shall not result in a loss of warranty. Mounting Procedure  Varování • Do not handle the screws on the device back side! Make a hole of the size of 139.5 (h) ×...
  • Page 30 2N Access Unit M Installation Manual Replace the cover onto the box. The box works as a strut while walling in. If the box location is convenient, wall the box in. 30 /  67...
  • Page 31 2N Access Unit M Installation Manual When the walling material has hardened, break off the box side stops. 31 /  67...
  • Page 32 2N Access Unit M Installation Manual Remove the cover from the box. Pull the metal holder downwards on the device back side to remove it. 32 /  67...
  • Page 33 2N Access Unit M Installation Manual Fit the holder to the box cover using the included screws. 33 /  67...
  • Page 34 2N Access Unit M Installation Manual Pull the cables leading from the device through the cover hole. Press the holder screwed to the cover to the device and move it upwards carefully to make the holder stops drive under the screw heads on the device back side.
  • Page 35 2N Access Unit M Installation Manual Insert the wires in the box keeping in mind that the maximum cable length is 250 mm. 35 /  67...
  • Page 36 2.2.3 Installation on Mounting Backplate ® The Mounting Backplate allows you to install cables below 2N  Access Unit M for surface mounting.  ...
  • Page 37 2N Access Unit M Installation Manual Mounting procedure:  Varování Do not handle the screws on the device back side! Prepare dowel holes on a selected place and in a selected height using a drilling template shown on the package. Cut a cable installation hole in the backplate.
  • Page 38 2N Access Unit M Installation Manual Pull the metal holder downwards on the device back side to remove it. 38 /  67...
  • Page 39 2N Access Unit M Installation Manual Put the cables in the backplate and put the backplate against the wall. If you connect the device to installed cables, connect the wires.  Varování • Insulate the wire joints with a shrink tube and glue to keep the cover rating as much as possible.
  • Page 40 2N Access Unit M Installation Manual Put the device against the backplate and insert the remaining cables carefully in the backplate. 40 /  67...

  • Page 41: Electric Installation

    2.3 Electric Installation 2N Access Unit M can be fed either from an external 12 V / 1 A DC power supply or from a PoE 802.3af supporting LAN. External Power Supply Use a 12 V ±...

  • Page 42: Connection To Lan

    2N Access Unit M Installation Manual Connection to LAN 2N Access Unit M is connected to the LAN using a UTP/STP cable (category Cat-5e or higher) via the dedicated LAN connector. As the device is equipped with the Auto-MDIX function, you can use both the straight and crossed cable version.
  • Page 43 2N Access Unit M Installation Manual Status Power Consumption 91611 91611 916114 91611 916115 916115 91611 9161161 At relax 1.6 W 1.6 W 1.5 W 1.5 W 1.5 W 1.5 W 1.5 W 1.5 W LED – white strip 0.12 0.12...
  • Page 44 2N Access Unit M Installation Manual Description of 2N Access Unit M Cabling 16112, 916114, 916115, 916116 9161121, 9161141, 9161151, 9161161 All the available cables are 35 cm long. The The LAN cable is 3 m long and terminated with LAN cable is terminated with RJ45 female.
  • Page 45 COM Cable Joining The 2N Access Unit M signals are led by insulated wires, which are 1 cm stripped at the ends (excluding the Ethernet cable with a connector). The cables can be joined using any of the below listed methods: •...
  • Page 46 2N Access Unit M Installation Manual  • Output wiring diagram for Relay  Wiring diagram for the controlled device’s electric circuit closing    Wiring Diagram for controlled device’s electric circuit opening     46 /  67...
  • Page 47 Security • The 12 V output is used for lock connection. If, however, the unit (2N IP Intercom, 2N Access Unit) is installed where unauthorized tampering may happen (building envelopes), we strongly recommend that Security Relay (Part No. 9159010) be used for enhanced installation security.

  • Page 48: Extending Module Connection

    The Security Relay (Part No. 9159010) is used for enhancing security between the access unit and the connected electric lock. It significantly enhances security of the connected electric lock as it prevents unlocking by forced opening of 2N Access Unit M. Function: The Security Relay is a device installed between the access unit (outside the secured area) and...

  • Page 49: Installation

    • To the passive output in series with an external power supply. The device also supports a Departure button connected between the ‘PB’ and – Helios/2N IP intercom’ terminals. Press the Departure button to activate the output for 5 seconds.
  • Page 50 2N Access Unit M Installation Manual • Activate the output switch using the keypad, telephone, etc. The first code sent from the intercom will be stored in the memory and considered valid. After code initialization, the Security Relay will pass into the operational mode (the green LED is blinking).
  • Page 51 Security Relay using the instructions above.  • FAQ: 2N® Security Relay – description of the device and use with the 2N IP intercoms  • Video Tutorial: 2N IP Door Intercoms – Security Relay Sorry, the widget is not supported in this export.
  • Page 52 2N Access Unit M Installation Manual Connection: 52 /  67...

  • Page 53: Detection Of 2N Access Unit M Using 2N® Network Scanner

    ® Network Scanner Description The application helps you find the IP addresses of all the 2N Access Unit M devices in the LAN. Download the app from the 2N web sites (www.2n.cz). Make sure that Microsoft .NET Framework 2.0 is installed for successful app installation.
  • Page 54 Window of 2N IP Network Scanner Select the 2N Access Unit M device to be configured and right-click it. Select Browse… to open the 2N Access Unit M administration web interface login window for configuration. To change the device IP address, select Config and enter the required static IP address or activate DHCP.
  • Page 55 2N Access Unit M Installation Manual ® IP Network Scanner IP Address Change 55 /  67...

  • Page 56: Factory Reset

     Note • The 2N Access Unit M time interval between the short press of the RESET button and reconnection of the device to the network is 26 s. IP Address Finding Follow the instructions below to identify the current IP address: •...
  • Page 57 2N Access Unit M Installation Manual • Wait until the red and green LEDs go on simultaneously on the device and the acoustic signal can be heard (approx. 15–35 s). • Wait until the red LED goes off and the acoustic signal can be heard (approx.
  • Page 58 2N Access Unit M Installation Manual   Factory Reset Follow the instructions below to reset the factory default values: • Press and hold the RESET button. • Wait until the red and green LEDs go on simultaneously and the acoustic signal can be heard (approx.

  • Page 59: Maintenance

    2N Access Unit M Installation Manual 5. Maintenance If used frequently, the device, its keypad in particular, gets unavoidably dirty. Use a piece of soft cloth moistened with clean water to clean the device. You are recommended to follow the principles below while cleaning: •...

  • Page 60: Status Signaling

    2N Access Unit M Installation Manual 6. Status Signaling The 2N Access Unit M operational statuses are indicated by a light signal on the device front side. The light signal can be accompanied with an acoustic signal if set so. Refer to 5.3.3 Audio...

  • Page 61: Technical Parameters

    2N Access Unit M Installation Manual 7. Technical Parameters Audio • Loudspeaker: 1 W / 8 Ω Power Supply • 12 V ±15 % / 1 A  • PoE 802.3af (Class 0–12.95 W) Interface • LAN: 10/100BASE-TX with Auto-MDIX, RJ-45 male (pigtail) •...

  • Page 62: General Drawings

    2N Access Unit M Installation Manual • Storage temperature: −40 °C to 70 °C • Dimensions: 132 (H) x 50 (W) x 27 (D) [mm] • Weight: 460 g • Covering level: IP55 (for basic surface main unit mounting, 2.2.1 Surface Mounting) 7.1 General Drawings...

  • Page 63: Supplementary Information

    2N Access Unit M Installation Manual 8. Supplementary Information • 8.1 General Instructions and Cautions • 8.2 Troubleshooting • 8.3 Other Countries' Legislation • 8.4 Directives, Laws and Regulations 8.1 General Instructions and Cautions Please read this User Manual carefully before using the product. Follow all instructions and recommendations included herein.

  • Page 64: Troubleshooting

    Make sure that the devices to be disposed of are complete. Do not throw battery packs into fire. Battery packs may not be taken into parts or short-circuited either. 8.2 Troubleshooting For the most frequently asked questions refer to faq.2n.cz. 64 /  67...

  • Page 65: Other Countries' Legislation

    8.3 Other Countries' Legislation Thailand 8.4 Directives, Laws and Regulations ® Access Unit M conforms to the following directives and regulations: • 2014/53/EU for radio equipment • 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment •...
  • Page 66 / devices of other suppliers, the customer agrees that the 2N TELEKOMUNIKACE a.s. company shall not be held liable for any functionality limitation of such a product or any damage, loss or injury related to this potential functionality limitation.
  • Page 67 Instalační manuál 2N Access Unit M 67 /  67...
