2N Access Unit M User Manual

2N Access Unit M User Manual

Hide thumbs Also See for Access Unit M:
Table of Contents

Advertisement

Quick Links

Download this manual
2N Access Unit M
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Access Unit M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for 2N Access Unit M

Summary of Contents for 2N Access Unit M

  • Page 1 2N Access Unit M User manual...

  • Page 2: Table Of Contents

    Table of Contents Symbols and Terms Used ........................ 3 Product Description ........................4 Basic Features ..........................4 Product Versions ..........................5 Accessories ........................... 6 Accessories for Installation ......................6 Extenders ........................... 7 Electric Locks ..........................8 Power Supply ..........................14 Licenses ...........................

  • Page 3: Symbols And Terms Used

    Symbols and Terms Used Symbols and Terms Used The following symbols and pictograms are used in the manual: DANGER Always abide by this information to prevent persons from injury. WARNING Always abide by this information to prevent damage to the device. CAUTION Important information for system functionality.

  • Page 4: Product Description

    2N Access Unit M is designed as a robust, The installation of 2N Access Unit M is very easy. All you have to do is connect the system to your LAN via a mains cable. Feed the device from a 12 V power supply or your PoE supporting LAN.

  • Page 5: Product Versions

    • Mobile Key Part No. 9161141 Axis Part No. 02910-001 2N Access Unit M RFID – 125 kHz, 13.56 MHz, NFC Combining an access reader and a controller, the device is used for access control inside and outside of buildings.

  • Page 6: Accessories

    Part No. 9161161 Axis Part No. 02912-001 2N Access Unit M Touch keypad & RFID – 125 kHz, 13.56 MHz, NFC Combining an access reader, a touch keypad and a controller, the device is used for access control inside and outside of buildings.

  • Page 7: Extenders

    Product Description Part No. 916121 Axis Part No. 02940-001 Flush Mounting Box The flush mounting box is used for connection and storage of cables below the device. Part No. 916122 Axis Part No. 02932-001 Mounting backplate The wall mounting backplate is used for connection and storage of cables below the device.

  • Page 8: Electric Locks

    Product Description Electric Locks Part No. 11202101 Electric opener Mini 5 series – short The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Features: • short sheet metal front cover version (130 mm) •...
  • Page 9 Product Description Part No. 11202103 Electric opener Mini 5 series with mechanical blocking – short The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Features: Part No. 11202103-L Electric opener Mini 5 series with mechanical blocking – long The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Features:...
  • Page 10 Product Description Part No. 11202105 Electric fail safe opener Mini 5 series with mechanical blocking – short The electric opener is designed for door frame installation, especially for such narrow profiles as aluminum, wooden or PVC frames Under voltage, the opener is secured, i.e. blocked, once voltage is stopped, the opener is unblocked and the door can be opened.
  • Page 11 The self-locking 72/55 lock with panic function is a suitable solution for emergency exits. A key is necessary to open the door from the outside (or an electric pulse from a connected 2N IP intercom/reader). Part No. 11202201-M Electromechanical lock SAM 7255 with monitoring The self-locking 72/55 lock with panic function is a suitable solution for emergency exits.
  • Page 12 Product Description Part No. 11202302 Cable bushing FX510 Provides secure passage and protection of the power cable between the door frame and the door wing. Features: • 510 mm length Part No. 11202303 Cable protector FX300G Provides secure passage and protection of the power cable between the door frame and the door wing.
  • Page 13 Interconnectable with a motion sensor and electronic access control system. Can be used both for the right and left doors and is available in the IN/OUT opening design. FAQ: Electric locks – Differences between locks for 2N IP access systems...

  • Page 14: Power Supply

    Designed for external supply of electric locks. Part No. 9159052 Axis Part No. 01393-001 12 V / 1 A power supply for 2N Induction Loop The external induction loop power supply has 230 V AC input voltage and 12 V DC output voltage.

  • Page 15: Licenses

    Product Description Licenses Part No. 9137909 Axis Part No. 01380-001 Gold License Includes the Enhanced Video, Enhanced Integration and Lift Control licenses. Part No. 9137910 Axis Part No. 01381-001 InformaCast License Other accessories...
  • Page 16 Product Description Part No. 9159013 Axis Part No. 02523-001 Departure button The departure button is connected to the device logic input for opening the door from inside the building. Part No. 9159012 Axis Part No. 01388-001 Magnetic door contact Set for installation on a door, enabling the status of door opening to be ascertained.
  • Page 17 Product Description Part No. 9134166E Axis Part No. 01396-001 RFID chip fob EM, 125 Hz RFID chip fob, type EM4100, 125 kHz. Part No. 11202601 Axis Part No. 02787-001 RFID chip card MIFARE DESFire, 13.56 MHz RFID chip fob, type MIFARE DESFire EV3 4 K, 13.56 MHz (ISO/ IEC14443A).
  • Page 18 • FeliCa (Standard, Lite) • ST SR (SR, SRI, SRIX) • Mobile Key The device can also read the 13.56 MHz 2N PICard RFID cards. Part No. 9137424E Axis Part No. 01527-001 External secured RFID reader, 13.56 MHz + 125 kHz, NFC/HCE External secured RFID card reader connectable to a PC via a USB interface.

  • Page 19: Package Completeness Check

    IP de- vice. You do not have to configure anything, all you need is one 2N 2Wire unit at each end of the cable and a power supply connected to at least one of these units.
  • Page 20 Product Description 2N Access Unit M Certificate of ownership Quick Start manual Metal wall holder (screwed to the device) 8 mm dowel Screw with a washer Screw for fitting the device in the holder Torx key (10/20 size)

  • Page 21: Installation

    If the difference is too great, separate the device in terms of pressure (using, e.g., a mounting box) and seal the cable passage. Surface Installation 2N Access Unit M is designed for surface mounting in its basic package without accessories (wall, plaster- board, door frames).
  • Page 22 Installation What you need for mounting: • 2N Access Unit M • Metal wall holder (screwed to the device)

  • Page 23: Surface Installation On Mounting Backplate

    Then fit the holder through the dedicated holes using the screws enclosed. Interconnect the accessible cables with the cabling 2N Access Unit M. Put the device carefully on the installed holder from above downwards and fix its position on the holder carrying elements by tightening the screw from the bottom through the holder hole.
  • Page 24 Shortening the LAN cable in units Part No. 9161121, 9161141, 9161151 and 9161161 shall not render the warranty null and void. What you need for mounting: • 2N Access Unit M • Mounting backplate (Part No. 916122) • Metal wall holder (screwed to the device)
  • Page 25 Installation WARNING Do not handle the screws on the device back side!

  • Page 26: Flush Mounting

    When the device touches the holder carrying elements, fix the device position by tightening the screw through the holder hole from the bottom. Flush mounting The flush mounting box allows you to place cables in the wall below 2N Access Unit M and mount the device. NOTE Shortening the LAN cable in units Part No.
  • Page 27 Installation What you need for mounting: • 2N Access Unit M • Flush mounting box (Part No. 916121) • Metal wall holder (screwed to the device)
  • Page 28 Installation...
  • Page 29 Installation WARNING Do not handle the screws on the device back side!

  • Page 30: Electric Installation

    Push the device upper part to fix the device in the final position. Electric Installation Power Supply 2N Access Unit M can be fed either directly from the LAN if equipped with PoE 802.3af supporting network elements or from an external 12 V ±15 % / 1 A DC power supply. WARNING 2N Access Unit M cannot be fed from an external power supply and PoE at the same time.

  • Page 31: Cabling Description

    Installation Current consumption [A] Available power output [W] Cabling Description Figure 1. Cable connection for Part Nos. Figure 2. Cable connection for Part 9161121, 9161141, 9161151, 9161161 Nos. 916112, 916114, 916115, 916116 The LAN cable is RJ-45 female terminated. All the available cables are 35 cm long.
  • Page 32 Installation Legend Component Description to fig- RELAY Relay cable with a 30 V / 1 A AC/DC NO/NC contact. Used for connec- tion of non-critical devices only (lights, e.g.). Input 1/2 The IN1, IN2 and IN3 terminals are used as inputs in the passive/active mode (−30 V to +30 V DC) for departure button, open door sensor, ESS etc.

  • Page 33: Cable Connection

    Cable Connection The 2N Access Unit M signals are led out by insulated wires stripped 1 cm at the ends (this does not apply to the Ethernet cable with a connector). Choose any of the below mentioned methods to connect the wires: •...

  • Page 34: Overvoltage Protection

    0.7 W 0.7 W Overvoltage Protection The 2N device cables have to be protected against atmospheric overvoltage caused by external causes (lightning, e.g.). A surge can damage a device installed outside/inside the building if the wires are unprotec- ted. Therefore, we recommend that additional overvoltage protectors (OVP) be installed on the outer walls or roof for all the wires leading outside the building.
  • Page 35 Installation • Make sure that the overvoltage protector is installed as close as possible to the device installed outside the building. • Make sure that the overvoltage protector is installed as close as possible to the device installed on an external part of the building.
  • Page 36 Installation Figure 4. Overvoltage protection installation diagram for a device installed on the building facade and cables inside the building...
  • Page 37 Installation Figure 5. Overvoltage protection installation diagram for a device and cables installed outside the building...

  • Page 38: Brief Guidelines

    Factory Default Reset (p. 40) Device Configuration Interface Access 2N Access Unit M is configured via the administration web interface. Connect the device to the LAN IP and make sure it is properly powered. You have to know the IP address for access.

  • Page 39: Ip Address Retrieval

    • Use the freely accessible 2N Network Scanner. • Use hardware (RESET button). Firmware Update We recommend that the firmware is also updated during the 2N Access Unit M installation. Refer to 2N.com for the latest FW version. Update firmware via the web configuration interface in System > Maintenance, refer to the device Configura- tion Manual.

  • Page 40: Restart Using Web Configuration Interface

    Restart the device in System > Maintenance > System using Restart . Factory Default Reset Follow the instructions below 2N Access Unit M to reset the factory default values: Factory Default Reset Press and hold the RESET button.

  • Page 41: Device Control

    • by entering a numeric access code via a keypad. Signaling of Operational Statuses The operational statuses 2N Access Unit M are indicated by a light on the device front side. The light signal can be accompanied with an acoustic signal if set so. Refer to 5.3.3 Audio...

  • Page 42: Maintenance - Cleaning

    Maintenance - Cleaning Maintenance - Cleaning If used frequently, the device surface gets dirty. Use a piece of soft cloth moistened with clean water to clean the device. It is recommended that the principles below are followed while cleaning: • Use appropriate cleaning agents suitable for glasses, optical devices, screens, etc. •...

  • Page 43: Troubleshooting

    Troubleshooting Troubleshooting Refer to faq.2n.cz for the most frequently solved problems.

  • Page 44: Technical Parameters

    Technical Parameters Technical Parameters Power Supply Types IEEE 802.3af, Class 0 (0.44–12,95 W) External supply 12 V ±15 % / 1 A DC Audio Speaker 1 W / 8 Ω Audio power output 1.9 W Interface 10/100BASE-TX s Auto-MDIX, RJ-45 Recommended cabling Cat-5e or higher Supported protocols...
  • Page 45 Technical Parameters Tamper Switch (part of the 2N Access Unit M main unit) Inputs Can be used in passive or active mode (-30 V to +30 V DC) • OFF = open or U > 1.5 V • ON = short-circuited or U <...
  • Page 46 Technical Parameters Mechanical Parameters Cover Robust ASA/PC construction material, which is also used for such car parts as lateral mirrors, radiator masks, etc. + chemically hardened 3 mm thick glass Dimensions (w x h x d) 132 x 50 x 27 mm Weight 460 g Operating temperature...

  • Page 47: Directives, Laws And Regulations - General Instructions And Cautions

    Directives, Laws and Regulations - General Instructions and Cautions 2N Access Unit M conforms to the following directives and regulations: • 2014/53/EU for radio equipment • 2011/65/EU on the restriction of the use of certain hazardous substances in electrical and electronic equipment •...
  • Page 48 / devices of other suppliers, the customer agrees that the 2N TELEKOMUNIKACE a.s. company shall not be held liable for any functionality limitation of such a product or any damage, loss or injury related to this potential functionali- ty limitation.
  • Page 49 Directives, Laws and Regulations - General Instructions and Cautions All applicable legal regulations concerning the product installation and use as well as provisions of technical standards on electric installations have to be obeyed. The manufacturer shall not be liable and responsible for damage or destruction of the product or damage incurred by the consumer in case the product is used and handled contrary to the said regulations and provisions.
  • Page 50 2N Access Unit M – User manual © 2N Telekomunikace a. s., 2024 2N.com...
